Kaixin MSU1 User Manual

Full digital mechanical sector scanning ultrasonic diagnostic instruments (vet)
Table of Contents

Advertisement

Quick Links

KAIXIN
Soll nicht übersetz werden – nur als Hilfsmaterial gedackt
MSU1
User's Manual
Information for Users
®
Full Digital Mechanical Sector Scanning
Ultrasonic Diagnostic Instruments (Vet)
XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSU1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kaixin MSU1

  • Page 1 KAIXIN ® Soll nicht übersetz werden – nur als Hilfsmaterial gedackt MSU1 Full Digital Mechanical Sector Scanning Ultrasonic Diagnostic Instruments (Vet) User’s Manual XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD. Information for Users...
  • Page 2 This user’s manual and intellectual property right (including copyright) herewith included is property of Kaixin. No persons may use, disclose or allow a third party to obtain by any means any of the information contained herein without prior written consent of Kaixin. No persons may reproduce this user’s manual, in whole or in part, including but not limited to photography, photocopy, reprint or translation into any other language without prior written consent of Kaixin.
  • Page 3 Follow the procedure below if you need to return the purchased equipment: To obtain the right to return the goods, contact local dealer of Kaixin Company, indicating serial number of main unit, this number is located on the nameplate of main unit. Please mark the product model, the serial number of main unit and reason to return the product.
  • Page 4 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) User’s Manual V1.00 1. Warning Symbols and Definitions The following warning symbols are used in this manual to indicate safety level and other important items. Please remember these symbols and understand the meaning as you read this user’s manual. These symbols convey specific meanings as detailed in the table below: Symbols &...
  • Page 5: Table Of Contents

    Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) User’s Manual V1.00 Chapter One Technical Specifications………………………………………………………………1 Chapter Two Product Outline………………………………………………………………………2 2.1 Structure composition of the instrument……………………………………………………2 2.2 Name of parts and components……………………………………………………………2 2.3 Parts of the probe……………………………………………………………………………2 2.4 Function keys description………………………………………………………………….. 2 Chapter Three System Configuration………………………………………………………………3 Chapter Four...
  • Page 6 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) User’s Manual V1.00 6.4.8 Image Processing Adjustment………………………………………………………………11 6.5 Image Control………………………………………………………………………………11 6.5.1 Magnification Selection……………………………………………………………………11 6.5.2 Depth Range Selection……………………………………………………………………11 6.5.3 Local Zoom and Local Additive Color……………………………………………………12 6.5.4 Image Left/right Reverse……………………………………………………………………12 6.5.5 Image Up/down Reverse……………………………………………………………………12 6.5.6 Color Selection………………………………………………………………………………12 6.5.7 Image Freeze/Unfreeze……………………………………………………………………12 6.6 Puncture guide line and lithotripsy positioning line……………………………………12...
  • Page 7: Technical Specifications

    17. Puncture guide line and lithotripsy positioning line. 18. PAL-NTSC Conversion. 19. Energy saving. 20. Chinese-English Switch. 21. Obstetric report. Chapter Two Product Outline 2.1 Structure composition of the instrument MSU1 full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) are composed of...
  • Page 8: Name Of Parts And Components

    2.2 Name of parts and components Fig. MSU1 main unit sketch map 2.3 Parts of the probe (Take 3.5MHz mechanical sector probe for example) Fig. Parts name of 3.5MHz mechanical sector probe Name Function To convert electric signal to ultrasonic signal based on principle of converse piezoelectric effect.
  • Page 9: Chapter Four Operation Condition

    1. Main unit 1 unit 2. 3.5MHz mechanical sector probe 1 PC 3. Power adapter 1 PC 4. Internal battery 2 PCS 5. Charger 1 PC 6. Support bracket 1 PC 7. Arm-band 1 PC 8. Straps 2 PCS 9. Leather bag 1 PC 10.
  • Page 10: System Installation And Check

    Warning: 1. When instrument works abnormally, do stop working, turn off the power and check the reason, then contacts the KAIXIN Company about it. 2. Turn off power and pull out of the plug from socket after each ultrasonic diagnostic operation.
  • Page 11: Probe Installation

    5.2 Probe installation Warning: 1. The Kaixin ultrasonic probe shall be connected to the dedicated Kaixin ultrasonic system only. Select proper probe model according to the relevant instructions of ultrasonic diagnostic system. 2. Check the ultrasonic probe and connecting cable after diagnostic operation. Use of defective probe may cause electric shock.
  • Page 12: Install/Dismantle The Battery

    Attention: 1. Turn off the ultrasonic system before disconnecting the probe. Disconnecting the probe with system power on may damage the system or probe. 2. Before disconnecting the probe, place the cable and probe on a stable and leveled position so that the probe may not be damaged or injury person by unexpected fall.
  • Page 13: Shutter Release Installation

    1. Adapter has no switch. The isolation of the system with the MAINS used to unplug the adapter as the intended isolation means. 2. The device should be used only with power adapter provided by Kaixin Company. 3. To avoid damaging power adapter or harming people by unexpected fallen, make sure the...
  • Page 14: Probe Check Before And After Operation

    5.8 Probe check before and after operation Before and after ultrasonic diagnosis to check the probe or cable jacket whether has any abnormalities, such as cracks, bulge or oil leakage, whether it be cleaned or disinfected. 5.9 Main unit check before and after operation 5.9.1 Inspection before start-up Check the following items before starting the machine: 1.
  • Page 15: Chapter Six

    Chapter Six Functional Operation 6.1 Startup and Shutdown In shutdown status, press key, machine starts up, power indicator lights. In startup status, press key, machine shuts down, power indicator goes out. Please note that when shut down the machine, the time of pressing key is a rather long than normal pressing key. 6.2 System Functions Setting 6.2.1 Time Setting 1.
  • Page 16: Key Sound Setting

    5. Press direction keys to choose “numbers” or “characters” and press key to confirm; Or operate mouse to click “numbers” or “characters” to input; 6. If need modify the content, press key to quit the character input menu; press direction keys to delete input content;...
  • Page 17: Image Quality Adjustment

    mouse to switch M speeds; 3. In real-time mode, press key to exit M mode. 6.4 Image Quality Adjustment 6.4.1 Brightness and Contrast Adjustment In the startup default status, press key to quit the current using status, press direction keys , the adjustment bars of brightness and contrast will be displayed on the screen, adjust them according to actual need.
  • Page 18: Local Zoom And Local Additive Color

    6.5.3 Local Zoom and Local Additive Color In real time B mode, press key to enter main-menu and press direction keys to move cursor to “Local Zoom” in the display area and then press direction keys , a box appears, press direction keys or operate mouse to move the box to the position to be enlarged, the selected image be enlarged;...
  • Page 19: Image Storage And Recall

    selected body mark; 3. Press direction keys or operate mouse to change the probe mark position; press key to change probe mark direction; 4. Press key to quit body mark and probe mark status; 5. Press key to quit froze and body mark status. 6.8 Image storage and recall 6.8.1 Save image ...
  • Page 20: Case Report Processing Center V3.1 Software (Optional)

    press key again to input according to Step 4, the number (ID) only be made up of numbers, letters or underlines; 6. After inputting ID, press key and press direction keys to move cursor to image area and press key again to input according to Step 4; 7.
  • Page 21: General Measurement

    Chapter Seven General Measurement 7.1 Distance Measurement 1. In B, B/B or B/M mode, freeze desired image, the cursor is located in the “Measure” position of display area; 2. Press key, the measurement methods are showed in the lower left of the screen, press direction keys to choose “Distance”, press key again, the cursor will show “+”;...
  • Page 22: Slope/Heart Rate/Cycle Measurement

    and right key of mouse to clear all marks and data; 11. Press key or click the middle mouse to unfreeze, clear all marks and data and quit the measurement status.  Circumference/area measurement with trace method 1. In B, B/B mode, freeze desired image, the cursor is located in the “Measure” position of display area;...
  • Page 23: Chapter Eight Obstetric Measurement

    Chapter Eight Obstetric Measurement 8.1 Measurement and Calculation items Obstetric tables of the system including: 1.SWINE, 2. CANINE, 3. FELINE, 4. OVINE, 5. GOAT, which is reference for doctor. 8.2 Measurement of Gestational Age (GA) and Estimated Date of Confinement (EDC) Follow the steps below: 1.
  • Page 24: Chapter Nine System Maintenance

    Chapter Nine System Maintenance The system maintenance should be performed by the user and service engineer. Users shall be in full charge of maintenance, repair and operation of the system after purchasing the product. 9.1 Maintenance by users 9.1.1 System clean, disinfect and sterilize Warning : Turn off the instrument and pull out the power supply wire before cleaning every instrument of the system.
  • Page 25: Use And Maintenance For The Charging Battery

    9.1.2 Use and maintenance for the charging battery 1. Only use charger and corresponding model of battery provided by KaiXin Company. 2. The output port of adapter plugs into the input port of charger to charge; the minimum charging time is 3 hours and up to 6 hours.
  • Page 26: Troubleshooting

    9.2 Troubleshooting To ensure normal operation, users are recommended to prepare a proper maintenance and regular examination plan to regularly check on product safety performance. If any abnormity occur, timely contact International Trade Dept of Kaixin for support.
  • Page 27: System Maintenance

    If the following problems occur on starting up the machine, try to make corrections following the method in the table. If the problem remains unsolved, contact International Trade Dept of Kaixin for support. Trouble Correction Power light is off and no screen 1.
  • Page 28: Chapter Ten

    Chapter Ten Storage and Transportation Storage and Transportation 1. If the instrument is stored over 3 months, take out the instrument from the packing case, connect it to power supply for 4 hours, and then disconnect the power and place it in the case again following the direction indicated by arrows on the package.
  • Page 29 KAIXIN ELECTRONIC XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD. Kaixin Mansion, C-01. Economic Development Zone, Xuzhou, Jiangsu, China. Zip Code: 221004 Tel: +86-516-87732932/87733758 Fax: +86-516-87732932/87792848 Website: http://www.kxele.com E-mail: gm01@kxele.com Shanghai International Holding Corp. GmbH (Europe) Eiffestrasse 80, 20537 Hamburg, Germany Information contained in this manual is subject to change without further notice.
