Quantum ActiveScale X100 Installation Manual

Hide thumbs Also See for ActiveScale X100:

Table of Contents

Quick Links

Download this manual

ActiveScale

with ActiveScale OS 6.0.2 software

X100 Rackless Instalation Guide

6-68841-03, Rev. A

Table of Contents

Need help?

Do you have a question about the ActiveScale X100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Quantum ActiveScale X100

Page 1 ActiveScale with ActiveScale OS 6.0.2 software X100 Rackless Instalation Guide 6-68841-03, Rev. A...
Page 2 Quantum ActiveScale™ OS X100 Rackless Installation Guide, 6-68841-03, October 2021, Product of USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.
Page 3: Table Of Contents
1 Rackless ActiveScale X100 product overview ........
Page 4 8.1 About PDU requirements ..........106 8.2 Powering on the ActiveScale X100 components ......106 9 Final steps .
Page 5 ActiveScale™ OS X100 Rackless Installation Guide Contents 12.2 Provisioning the newly added sleds on a single site system ....172 12.3 Provisioning the newly added sleds on a multi-site system - .
Page 6 19 About ActiveScale X100 racks ........
Page 7 Contacting Quantum ........
Page 8: List Of Tables
Table 1-3. ActiveScale X100 identification ........
Page 9 ActiveScale™ OS X100 Rackless Installation Guide List of tables Table 15-19. Storage Enclosure Specifications ....... 231 Table 15-20.
Page 10 ActiveScale™ OS X100 Rackless Installation Guide List of tables Table 20-59. Output connector ratings ........256 Table 20-60.
Page 11: List Of Figures
ActiveScale™ OS X100 Rackless Installation Guide List of figures List of figures Figure 2-1. Minimum servicing space required ....... . 32 Figure 3-2.
Page 12 Figure 10-24. ActiveScale SM welcome screen ......130 Figure 10-25. A multi-site ActiveScale X100 system......133 Figure 10-26.
Page 13 Figure 10-52. ActiveScale SM welcome screen ......158 Figure 10-53. The dashboard for a single site ActiveScale X100 ....159 Figure 11-54.
Page 14 Figure 21-20. Components and port identification......262 Figure 21-21. ActiveScale X100 cable wiring key ......263...
Page 15: Rackless Activescale X100 Product Overview
However, for customers who purchase the ActiveScale™ X100 and who prefer or need to use their own racks, the components of the system are disassembled, re-boxed, and shipped as the rackless ActiveScale™ X100 . This document describes the re-assembly of the re-boxed ActiveScale X100. Topics: •...
Page 16: About Shipping Pallets And Boxes
ActiveScale™ OS X100 Rackless Installation Guide 1.1 About shipping pallets and boxes The components of a rackless ActiveScale X100 system are shipped on three pallets. Table 1-1. Contents of ActiveScale X100 shipping pallets Pallet Boxes Contents 4 Storage Enclosure Basic boxes...
Page 17 ActiveScale™ OS X100 Rackless Installation Guide Table 1-1. Contents of ActiveScale X100 shipping pallets (continued) 6 x Storage Nodes Each Storage Node box: Pallet weight: 635 lbs Box weight: 65 lbs (30 kg) • Rail kits (288 kg) • Screws and fasteners Pallet Dimensions: •...
Page 18: System Specification Summary
ActiveScale™ OS X100 Rackless Installation Guide 1.2 System specification summary The following table is a summary of specifications relevant to the ActiveScale X100. Condition (fully configured) Non-operating Operating Altitude -984 ft to 39,3711 ft -984 ft to 10,000 ft (-300 m to 12,000 m) (-300 m to 3048 m) •...
Page 19 ActiveScale™ OS X100 Rackless Installation Guide Condition (fully configured) Non-operating Operating Thermal output Base configuration (one column of populated sleds): • 8.53/11.26 KBTU/h Base +1 configuration (two column of populated sleds): • 10.75/13.59 KBTU/h Base +2 configuration (three column of populated sleds): •...
Page 20: Summary Of Installation Phases
ActiveScale™ OS X100 Rackless Installation Guide 1.3 Summary of installation phases Table 1-2. Installation phases Chapter Steps Phase 1 - • Verifying rack Preparing the dimensions rack • Verifying front and rear working space • Verifying interior rack space (in front of and behind vertical rails) •...
Page 21 ActiveScale™ OS X100 Rackless Installation Guide Table 1-2. Installation phases (continued) Chapter Steps Phase 2 - 6 Storage Enclosure Installing Basics Storage • Unpacking boxes Enclosure • Installing rails Basics • Installing chassis • Installing sleds • Installing I/O module with SAS cables and power cables...
Page 22 ActiveScale™ OS X100 Rackless Installation Guide Table 1-2. Installation phases (continued) Chapter Steps Phase 3 - 6 Storage Nodes Installing the • Installing rails (leaving Storage Nodes 1U gap above last Storage Enclosure Basic) • Installing servers • Connecting SAS cables...
Page 23 ActiveScale™ OS X100 Rackless Installation Guide Table 1-2. Installation phases (continued) Chapter Steps Phase 4 - 3 System Nodes Installing the • Installing rails System Nodes • Installing servers...
Page 24 ActiveScale™ OS X100 Rackless Installation Guide Table 1-2. Installation phases (continued) Chapter Steps Phase 5 - 2 System Interconnects Installing the • Installing rails System • Installing System Interconnects Interconnects • Connecting DAC cables...
Page 25 ActiveScale™ OS X100 Rackless Installation Guide Table 1-2. Installation phases (continued) Chapter Steps Phase 6 - 1 Management Installing the Interconnect Management • Installing rails Interconnect • Installing the Management Interconnect • Connecting Cat6 Ethernet cables...
Page 26 Interconnect to power the ActiveScale X100. • Connecting Storage Enclosure Basics to power • Connecting Storage Nodes to power • Connecting System Nodes to power • Powering on the ActiveScale X100 A fully assembled ActiveScale X100 is shown in the figure below:...
Page 27: Table 1-3. Activescale X100 Identification
ActiveScale™ OS X100 Rackless Installation Guide Table 1-3. ActiveScale X100 identification Number Component Management Interconnect System Interconnects (blanking panels not shown) Note: There is no requirement to leave space between System Interconnects in a racked ActiveScale X100. System Nodes Storage Nodes...
Page 28 ActiveScale™ OS X100 Rackless Installation Guide...
Page 29: Preparing The Rack
Phase 1 of the installation process consists of verifying that the rack and its location meet specifications. Quantum Corporation recommends removing the front and rear doors to the rack before assembling. If possible, Quantum Corporation also recommends removing the side panels of the rack for assembly.
Page 30: Verifying Rack Requirements
Rack requirements on page 242. However, Quantum Corporation has found that choosing a rack based solely on the measurements provided can sometimes lead to unexpected and unsatisfactory results. Consequently, Quantum Corporation recommends that you consider the items in the table below when choosing a rack for the...
Page 31: Table 2-4. Rack Considerations For The Activescale X100
• If you are using horizontal PDUs, you will need to add additional U space to the 38U ActiveScale X100 requirement. • If other equipment will also reside in the rack, you will need to ensure that ActiveScale X100 has at least 38Us as well as sufficient open power receptacles in the PDUs.
Page 32: Servicing Space Requirement
Top of Rack REAR FRONT 2.3 PDU considerations Quantum Corporation recommends that you install and connect the PDUs during the phase Powering the ActiveScale X100 on page 105. If the rack you are working on already has the PDUs installed, consider removing them from the rack to facilitate the installation of the Storage Enclosure Basics and System Interconnects.
Page 33: System Serial Number
Each ActiveScale X100 system has a serial number, and each component of the ActiveScale X100 that is installed in the rack is labeled with this serial number. As you assemble the ActiveScale X100, verify that the serial numbers on all components match.
Page 34 ActiveScale™ OS X100 Rackless Installation Guide...
Page 35: Installing The Storage Enclosure Basics
ActiveScale™ OS X100 Rackless Installation Guide 3 Installing the Storage Enclosure Basics Phase 2 of the install process consists of installing six Storage Enclosure Basics. Topics: • Identification of assembled Storage Enclosure Basic on page 37 • About assembling the Storage Enclosure Basic on page 37 •...
Page 36 ActiveScale™ OS X100 Rackless Installation Guide • Assemble the remaining Storage Enclosure Basics on page 66...
Page 37: Identification Of Assembled Storage Enclosure Basic
ActiveScale™ OS X100 Rackless Installation Guide 3.1 Identification of assembled Storage Enclosure Basic The following figure displays the major components of an assembled Storage Enclosure Basic: Figure 3-2. Identification of assembled Storage Enclosure Basics 3.2 About assembling the Storage Enclosure Basic The Storage Enclosure Basics are designed to be installed in sequential order in the rack.
Page 38: Unpacking A Storage Enclosure Basic
3.2.1 Unpacking a Storage Enclosure Basic When unpacking a Storage Enclosure Basic, perform the following steps: 1. Identify the box that has the Storage Enclosure Basic label. As you assemble the ActiveScale X100 open, Storage Enclosure Basic boxes in sequential order.
Page 39: Installing The Rail Kit
Note: Extra screws are included in the ActiveScale X100 accessory box. Table 3-6. Required tools Number 2 Phillips-head screwdriver with a 12" shaft.
Page 40 ActiveScale™ OS X100 Rackless Installation Guide 1. If you haven't already done so, remove the rail kit from the box and unpack hardware contained within the packaging. 2. Determine the location you would like to mount the first rail. In some rack positions where the rack frame may create difficult access to the cable channel, you may choose to pre-thread the power cables and the SAS cables through the rails before mounting them.
Page 41 ActiveScale™ OS X100 Rackless Installation Guide 4. Push the front of the rail back until it is flush behind the front vertical rail and insert screws with washers in the top and bottom holes of the rail. Note: The chamfered side of the washer goes toward the rack. Tip: If you drop or lose a screw, look for the bag of extra screws included in the accessory kit.
Page 42 ActiveScale™ OS X100 Rackless Installation Guide 5. Align the back end of the rack mount rail with the back of the rail. 6. Loosely insert four screws to secure the back end of the rail to the rear vertical rail. 7.
Page 43 ActiveScale™ OS X100 Rackless Installation Guide 10. Thread the SAS cables and the power cable between the front vertical rail and the front of the cabinet.
Page 44: Installing The Chassis
ActiveScale™ OS X100 Rackless Installation Guide 11. From the back of the rack, on the right side of the rack, run the power cable through the channel on the side of the rail and thread it between the front vertical rail and the front of the cabinet. After the rail kit is installed, you are ready to install the Storage Enclosure Basic chassis.
Page 45: Figure 3-3. Rack Ears
ActiveScale™ OS X100 Rackless Installation Guide To install the chassis, do the following: 1. If you have not already done so, remove the chassis from the box. 2. Attach the first rack ear to the front outside of the of the chassis with 5, M4 X 8 Torx screws. Important: Leave the screws loose;...
Page 46: Figure 3-4. Chassis
3. Repeat the previous step for the remaining rack ear. Note: Each side contains 5, M4 X 8 Torx screws. Caution: Due to the size and weight of the chassis, Quantum Corporation recommends using two people to lift and install the chassis 4.
Page 47: Figure 3-5. Chassis Sidewall Screws
ActiveScale™ OS X100 Rackless Installation Guide 6. From the inside of the chassis, secure the sides of the chassis to the rails using 3, M4 X 8 screws. Note: Each side should contain 3 screws in the sidewall of the chassis. Figure 3-5.
Page 48: Figure 3-6. Front Rack Ears And Rack Mount Rail Screw Configuration
ActiveScale™ OS X100 Rackless Installation Guide 7. Repeat previous step to secure the other side of the chassis to the rails. 8. After the inside screws are in place, tighten all 6 screws completely. 9. On the left side of the chassis, fully tighten the 5 rack ear screws. 10.
Page 49: Installing The Sleds
ActiveScale™ OS X100 Rackless Installation Guide Note: Each side contains 4, M5 X 12 screws. 12. Follow the two previous steps to attach the other rack ear and rack mount rail. 13. On the left side of the rack, push the edge of the chassis to the left until it is flush with, or just slightly to the left of, the front face of the vertical rail.
Page 50: Figure 3-7. Front And Rear View Of Sled
• Populated sleds must be added to Storage Enclosure Basics in one column increments. That is, ActiveScale X100 systems are scaled up in increments of six sleds. Figure 3-7. Front and rear view of sled Warning: To prevent damage to sled components and connectors, do not put any weight on either end of the sleds or stand the sleds on either end.
Page 51 ActiveScale™ OS X100 Rackless Installation Guide 1. Verify that the rack serial number is correct on the sled. 2. Identify the sled to insert. Begin with the sled labeled A. 3. Verify the Storage Enclosure Basic number on the sled label matches the chassis number and rack position.
Page 52: Figure 3-8. Seated Sled
ActiveScale™ OS X100 Rackless Installation Guide 6. Slide the sled into the chassis until it is securely seated against the rear of the chassis. Note: The sled can be inserted with the latch open or closed. Figure 3-8. Seated sled...
Page 53: Figure 3-9. Populated Chassis
ActiveScale™ OS X100 Rackless Installation Guide 7. Repeat steps 1 through 5 for all the remaining sleds. Ensure that all populated sleds are aligned contiguously on the left side of the chassis. Note: The final sled or sled blank will fit snugly. Be careful not to damage any of the chassis components.
Page 54: Installing The Rear Fans
ActiveScale™ OS X100 Rackless Installation Guide 3.6 Installing the rear fans Figure 3-10. Front and rear view of rear fan Note: Each fan is stamped with a letter. Insert fans behind the exhaust ports on the back of the chassis according to the corresponding letter printed on the back of the chassis.
Page 55: Figure 3-11. Rear Fan Installation
ActiveScale™ OS X100 Rackless Installation Guide 1. From the rear of the chassis, line the up the bottom of fan A with rubber bumpers on the chassis. 2. Tilt the top of the fan until the fan pins line up with the connectors on the chassis. Warning: To prevent damage to the rear fan components, press the at the top of the fan.
Page 56: Adjusting The Cord Retention Bale
The cord retention bale is adjustable to the size of different approved power cords. The retention bale should already be set correctly for the power cables supplied with the ActiveScale X100. You only need to adjust the cord retention bale if you are not using the Quantum Corporation-supplied cables.
Page 57: Installing The I/O Module
ActiveScale™ OS X100 Rackless Installation Guide 3.8 Installing the I/O module For the installation of the I/O module, the following hardware is required: Table 3-10. I/O module hardware Part description Quantity I/O module The I/O module contains the following components: •...
Page 58 ActiveScale™ OS X100 Rackless Installation Guide 1. Remove the I/O module from the box and unpack hardware contained within the packaging. 2. Verify that serial number on the I/O module matches the rack serial number. 3. On the I/O module, open the latch handle. 4.
Page 59: Figure 3-14. Installing The I/O Module
ActiveScale™ OS X100 Rackless Installation Guide Figure 3-14. Installing the I/O module...
Page 60: Figure 3-15. Seating The I/O Module
ActiveScale™ OS X100 Rackless Installation Guide 6. Using the open lever, slide the I/O module towards the sleds until it stops. Note: Do not push on the top of the I/O module. Maneuver and push it into postion using the open lever. Figure 3-15.
Page 61: Figure 3-16. I/O Module Handle
ActiveScale™ OS X100 Rackless Installation Guide 7. Verify that it is firmly in place. 8. Using both of the palms of your hands, press the latch handle up and into the I/O module until locked into the rack ears. Figure 3-16. I/O module handle...
Page 62: Connecting Power Cables
ActiveScale™ OS X100 Rackless Installation Guide Tip: You will hear an audible click, when the handle is correctly locked into place. Note: I/O module handle is marked in red. Rack ears are marked in yellow. 9. Verify that the I/O module fits firmly within the chassis. Figure 3-17.
Page 63: Figure 3-18. Open Latch Handle
ActiveScale™ OS X100 Rackless Installation Guide 1. From the front of the rack, unlatch the I/O module latch handle. Figure 3-18. Open latch handle Note: The latch handle should be opened until clear of the rack ears. I/O module handle is marked in red. Rack ears are marked in yellow. 2.
Page 64: Figure 3-19. Power Supply A
ActiveScale™ OS X100 Rackless Installation Guide orientation of the overmold in the removal latch slot. The figure is provided for orientation purposes only; do not insert the power cable into the removal latch slot while the latch is open. Note: Orient the neutral slot toward the front of the rack. Figure 3-19.
Page 65: Figure 3-20. Power Supply B
ActiveScale™ OS X100 Rackless Installation Guide 4. Connect the second power cable to power supply B. Do not fully seat the power cable. Note: The SAS cables will go in front of the power cable. Figure 3-20. Power supply B 5.
Page 66: Sanity Check
3.10 Sanity check After completely installing the first Storage Enclosure Basic, Quantum Corporation strongly recommends that you perform a sanity check before continuing with assembly of the ActiveScale X100. The sanity check consists of the following tasks: • Attach (or re-attach) the PDUs. Do not connect power to the PDUs.
Page 67 ActiveScale™ OS X100 Rackless Installation Guide Note: As you assemble the ActiveScale X100, there will be a number of power cables hanging out of the back of the rack. This is normal for the assembly process. Be sure to rack the Storage Enclosure Basics from the bottom up.
Page 68 ActiveScale™ OS X100 Rackless Installation Guide...
Page 69: Installing Storage Nodes
ActiveScale™ OS X100 Rackless Installation Guide 4 Installing Storage Nodes Phase 3 of the install process consists of installing six Storage Nodes and connecting SAS cables between the Storage Nodes and Storage Enclosure Basics. Topics: • Installing the Storage Nodes on page 70 •...
Page 70: Installing The Storage Nodes
Quantum Corporation products. When unpacking a Storage Node, perform the following steps: 1. Identify the box that has the Storage Node label. As you assemble the ActiveScale X100, open Storage Node boxes in sequential order. 2. Open the box.
Page 71: Figure 4-23. Expand The Outer Rail
ActiveScale™ OS X100 Rackless Installation Guide Note: When installing the rail kit for the first Storage Node, you can leave a 1U gap between the Storage Enclosure Basics and the Storage Nodes for serviceability. 1. Attach the outer rail to the rack. a.
Page 72: Figure 4-25. Rail Attaching To Front Vertical Rail
ActiveScale™ OS X100 Rackless Installation Guide c. Extend the outer rail forward and insert the pegs into the front vertical rail. The illustration below shows how the latch and the rail pegs attach to the rear vertical rail. Figure 4-25. Rail attaching to front vertical rail...
Page 73: Figure 4-26. Locking The Inner Rail To The Storage Node
ActiveScale™ OS X100 Rackless Installation Guide d. Extend the inner rail to its full length and remove the inner rail by sliding the white clip with a rounded edge forward. Note: Be cautious leaving the outer rails extending out of the rack. Consider pushing the outer rails back into the rack until step 3 below.
Page 74: Connecting Sas Cables
ActiveScale™ OS X100 Rackless Installation Guide b. Secure the inner rail to the Storage Node using one of the screws. c. Repeat steps a - b on the other side of the Storage Node using the other inner rail. 3. Align the rails on the Storage Node to the rails attached to the rack and push the Storage Node into the rack.
Page 75: Connecting Power Cables To The Storage Nodes
4.3 Connecting power cables to the Storage Nodes Connect two power cables to each Storage Node that has been installed in the rack. Note: Do not connect the power cables to the PDU until the phase Powering the ActiveScale X100 on page 105.
Page 76 ActiveScale™ OS X100 Rackless Installation Guide...
Page 77: Installing System Nodes
ActiveScale™ OS X100 Rackless Installation Guide 5 Installing System Nodes Phase 4 consists of installing the three System Nodes. Topics: • Installing the System Nodes on page 78 • Connecting power cables to the System Nodes on page 82...
Page 78: Installing The System Nodes
Quantum Corporation products. When unpacking a System Node, perform the following steps: 1. Identify the box that has the System Node label. As you assemble the ActiveScale X100, open System Node boxes in sequential order. 2. Open the box 3.
Page 79: Figure 5-28. Expand The Outer Rail
ActiveScale™ OS X100 Rackless Installation Guide 1. Attach the outer rail to the rack. a. Extend the outer rail enough that the far end of the outer rail can reach the rear vertical rail. Figure 5-28. Expand the outer rail b.
Page 80: Figure 5-30. Rail Attaching To Front Vertical Rail
ActiveScale™ OS X100 Rackless Installation Guide Figure 5-30. Rail attaching to front vertical rail...
Page 81: Figure 5-31. Locking The Inner Rail To The System Node
ActiveScale™ OS X100 Rackless Installation Guide d. Extend the inner rail to its full length and remove the inner rail by sliding the white clip with a rounded edge forward. Note: Be cautious leaving the outer rails extending out of the rack. Consider pushing the outer rails back into the rack until step 3 below.
Page 82: Connecting Power Cables To The System Nodes
5.2 Connecting power cables to the System Nodes Connect two power cables to each System Node that has been installed in the rack. Note: Do not connect the power cables to the PDU until the phase Powering the ActiveScale X100 on page 105.
Page 83: Installing System Interconnects
Phase 5 consists of installing the System Interconnects and connecting the Storage Nodes and System Nodes to the System Interconnects with DAC cables. Topics: • Installing the System Interconnects on page 84 • Cabling the System Interconnects on page 89 • Connecting the ActiveScale X100 to the customer network on page 96...
Page 84: Installing The System Interconnects
ActiveScale™ OS X100 Rackless Installation Guide 6.1 Installing the System Interconnects Required Tools Warnings Personnel Time #2 Phillips-head screwdriver 60 minutes When unpacking the System Interconnects, perform the following steps: 1. Identify the box that has the System Interconnect label. 2.
Page 85 ActiveScale™ OS X100 Rackless Installation Guide 1. From the accessory box, remove the System Interconnect rail kit. 2. From the front of the rack, attach the left external rail by extending the adjustable rear end to its full length and inserting the pegs into the back vertical rail. 3.
Page 86 ActiveScale™ OS X100 Rackless Installation Guide rack and then screw the front of the external rail in place. 5. From the back of the rack, align the flush face plate on the back vertical rail with the chamfered holes facing the back of the rack and then screw the back of the external rail in place. 6.
Page 87: Figure 6-32. Align And Install - System Interconnects
ActiveScale™ OS X100 Rackless Installation Guide Interconnects.) e. Slide the System Interconnect the rest of the way into the 3U rail kit until it stops. Figure 6-32. Align and install - System Interconnects...
Page 88 The figure below provides an illustration of how the back of the rack will look after the installation of the System Interconnects. Important: Do not connect the power cables to the PDU until the phase Powering the ActiveScale X100 on page 105.
Page 89: Cabling The System Interconnects
(i.e. the source location on the Storage Node or System Node) and destination (i.e. the destination location in the System Interconnect.) Note: Quantum Corporation recommends that you familiarize yourself with the cable labeling conventions found in...
Page 90: Figure 6-34. Cabling Storage Node 2
ActiveScale™ OS X100 Rackless Installation Guide Figure 6-34. Cabling Storage Node 2 Figure 6-35. Cabling Storage Node 3...
Page 91: Figure 6-36. Cabling Storage Node 4
ActiveScale™ OS X100 Rackless Installation Guide Figure 6-36. Cabling Storage Node 4...
Page 92: Figure 6-37. Cabling Storage Node 5
ActiveScale™ OS X100 Rackless Installation Guide Figure 6-37. Cabling Storage Node 5...
Page 93: Cabling The System Nodes
6.2.2 Cabling the System Nodes Begin cabling with System Node 1 and proceed through System Node 3 as shown in the figures below. You can also consult ActiveScale X100 cable wiring key on page 263 for another description of cable wiring.
Page 94: Figure 6-39. Cabling System Node 1
ActiveScale™ OS X100 Rackless Installation Guide Figure 6-39. Cabling System Node 1...
Page 95: Figure 6-40. Cabling System Node 2
ActiveScale™ OS X100 Rackless Installation Guide Figure 6-40. Cabling System Node 2...
Page 96: Connecting The Activescale X100 To The Customer Network
Figure 6-41. Cabling System Node 3 6.3 Connecting the ActiveScale X100 to the customer network Cables that connect the ActiveScale X100 to the customer network do not connect into the System Interconnects. Rather, they connect into N1 and N3 ports of the System Nodes.
Page 97: User Provided Cables
ActiveScale™ OS X100 Rackless Installation Guide 6.3.1 User provided cables To connect to the customer network, the customer must provide networking cables that are compatible with the SFP+ transceivers that are installed in the rear of each System Node. The transceivers require a multimode, duplex, fiber optic cable (50/125) with an LC connector at the appliance end of the cable.
Page 98 ActiveScale™ OS X100 Rackless Installation Guide...
Page 99: Installing The Management Interconnect
ActiveScale™ OS X100 Rackless Installation Guide 7 Installing the Management Interconnect Phase 6 consists of installing the Management Interconnect and connecting the Storage Nodes and System Nodes to the management interconnect with CAT6 Ethernet cables. Topics: • Installing the Management Interconnect on page 100 •...
Page 100: Installing The Management Interconnect
ActiveScale™ OS X100 Rackless Installation Guide 7.1 Installing the Management Interconnect Required tools Warnings Personnel Time • #2 Phillips head screwdriver None 30 minutes • Cage nut installation tool or flat head screwdriver The Management Interconnect was unpacked in the previous installation phase. Before installing the Management Interconnect verify that the rack serial number is correct on the Management Interconnect.
Page 101 ActiveScale™ OS X100 Rackless Installation Guide 1. Identify the box that has the System Interconnect label. 2. Remove the Management Interconnect and verify that the serial number matches the system serial number. 3. From the Management Interconnect box, locate the adapters for mounting the Management Interconnect in the rack.
Page 102: Cabling The Management Interconnect
ActiveScale™ OS X100 Rackless Installation Guide Interconnects. 6. Install two cage nuts in corresponding positions on the right side of the rack. 7. From the back of the rack, position the adapters of the Management Interconnect over the cage nuts and screw the adapters into place with the 4 screws provided.
Page 103: Figure 7-43. Cabling Diagram For The Management Interconnect
Figure 7-43. Cabling diagram for the Management Interconnect Note: The rackless version of ActiveScale X100 does not support monitoring PDUs. However, if you have purchased PDUs directly from Quantum Corporation specifically for ActiveScale X100, then contact customer support...
Page 104: Connecting A Power Cable To The Management Interconnect
ActiveScale™ OS X100 Rackless Installation Guide for instructions on cabling PDUs to the Management Interconnect and for enabling PDU monitoring in the ActiveScale X100 system. 7.3 Connecting a power cable to the Management Interconnect Connect a power cable to the Management Interconnect that has been installed in the rack. The power...
Page 105: Powering The Activescale X100
Phase 7 consists of the following steps: • Mounting PDUs in the rack and connecting them to power • Identifying appropriate receptacles in the PDU for the power cords of ActiveScale X100 components • Plugging component power cables into the PDU •...
Page 106: About Pdu Requirements
• PDUs should support 7kW (nominal) and 8.3kW (short term maximum) of power (North America, Japan). • Between all the PDUs, there should be at least 35 open receptacles for powering ActiveScale X100 components. Work with your data center electrician to ensure that the power going to, and coming out of, the PDUs is balanced.
Page 107 7. At the back of the rack, plug the power cords from the System Nodes into the PDU at the specified location. 8. Go to the front of the rack and, in ascending order, press the power button on each of the System Nodes. The ActiveScale X100 is now powered on, and the software is ready to be configured.
Page 108 ActiveScale™ OS X100 Rackless Installation Guide...
Page 109: Final Steps
There are a number of straps included in the accessory box that can be used to organize and move the cables to the sides of the ActiveScale X100 rack. After verifying that the ActiveScale X100 has been correctly assembled and successfully powered on, organize the cables in rack.
Page 110 ActiveScale™ OS X100 Rackless Installation Guide...
Page 111: System Bringup
Warning: If you have just completed the hardware installation of an additional system at the site (a scale out), stop here. For instructions on adding additional systems, see the ActiveScale X100 Support Guide. Figure 10-1. Initial bringup workflow Topics: •...
Page 112: Single Site Deployments
– Your filled-in ActiveScale X100 Site Survey. – The configuration wizard prompts you for the local network settings you predetermined through your ActiveScale X100 Site Survey. Please have your settings available for your reference. • A CAT6 (RJ45) cable for connecting your laptop to the system •...
Page 113: Figure 10-2. Location Of System Nodes: Label "4
ActiveScale™ OS X100 Rackless Installation Guide Important: The system must be completely powered on at this point. Warning: The 10GbE cables from SFP+ ports 1 and 3 on each System Node must not be connected to your network(s) at this point, to avoid possible IP conflicts.
Page 114: Figure 10-3. System Node Eth2 Port
ActiveScale™ OS X100 Rackless Installation Guide The figure below illustrates the location of the eth2 port. Figure 10-3. System Node eth2 port b. Give your laptop an IP address in the same range as the System Node's default link local IP address for eth2, 169.254.140.1 For example,...
Page 115: Figure 10-5. Pre-Login > Site Configuration
Pre-Login > Site Configuration 5. Edit the fields on the Site Configuration page according to your predetermined values as recorded in your ActiveScale X100 Site Survey. Note: All fields are mandatory. 6. (Optional) Enable NIC bonding on the public network interfaces.
Page 116: Figure 10-7. Pre-Login > Site Configuration > Bond Modes
ActiveScale™ OS X100 Rackless Installation Guide The NIC Bonding dialog box appears. Figure 10-7. Pre-Login > Site Configuration > Bond Modes b. From the pull-down menu, select a Bond Mode. Bond modes are: • bond-mode 0 (Round Robin): transmits packets in a sequential order from the first available slave through the last.
Page 117: Figure 10-9. Pre-Login > Site Review > Storage
ActiveScale™ OS X100 Rackless Installation Guide 8. Click each tab on the Site Review page to review your IP assignments. Warning: It is crucial that you correct any errors on this page. To make corrections, click Back and edit the settings. Warning: Once you navigate forwards to the Apply Progress page, you can no longer change Storage Network 1 and Storage Network 2 settings.
Page 118: Connect The System To Your Networks
ActiveScale™ OS X100 Rackless Installation Guide d. Click the IPMI tab. The wizard displays the IPMI IP addresses for the system. Check each IP assignment to make sure it’s correct. Verify that the IPMI IP addresses do not conflict. 9. Click Apply. The Apply Configuration page appears, with an estimate of the time remaining.
Page 119: Figure 10-12. System Node Ports For Public Network 1 And 2
1 (N1). Figure 10-12. System Node ports for Public Network 1 and 2 For racked ActiveScale X100 systems, feed the data center’s network cables through the cable routing brush strip on top of the rack: Figure 10-13. Network connection through top of rack Figure 10-14.
Page 120: Run The Post-Login Configuration Wizard (Single Site Version)
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-15. Network connectivity for a single site ActiveScale X100 10.2.4 Run the post-login configuration wizard (single site version) The post-login configuration wizard guides you through the remaining configurable items.
Page 121: Figure 10-16. Post-Login > Eula
ActiveScale™ OS X100 Rackless Installation Guide Note: Complete the steps in Connect the system to your networks on page 118 before starting the post-login configuration. Tip: All fields in the post-login configuration wizard are mandatory unless otherwise noted. 1. Start the post-login configuration wizard. a.
Page 122: Figure 10-17. Post-Login > Configuration
ActiveScale™ OS X100 Rackless Installation Guide 2. Complete the EULA section. a. Review the EULA in its entirety. b. At the bottom of the EULA, type the Name and Title of the system administrator. c. To download a copy of the EULA, click Download. d.
Page 123 Important: The Quantum Support Passcode is your portion of the two-factor password for the www.quantum.com/support user. It is limited to 20 characters. You can change it at any time to allow/deny access to your system by Quantum Support. f. Paste in your SSL certificates for ActiveScale SM and the S3 interface.
Page 124: Figure 10-18. Post-Login > S3
ActiveScale™ OS X100 Rackless Installation Guide If you have issues after selecting an SMTP server that the system cannot connect to, contact Quantum support. Tip: You can specify SMTP Server as an IP address or a fully qualified domain name (FQDN).
Page 125: Table 10-1. Storage Policies For A Single Site Activescale P100
ActiveScale™ OS X100 Rackless Installation Guide k. Enter your system’s geolocation information. Tip: Street Address, City, State, and Country are optional. Default Country is USA. Tip: Timezone is optional; it defaults to America/Los_Angeles (UTC-8). Choose a durability policy for the system. The table below describes the durability policies and how they behave with the default value for the small file threshold.
Page 126: Table 10-2. Storage Policies For A Single Site Activescale X100
ActiveScale™ OS X100 Rackless Installation Guide Table 10-2. Storage policies for a single site ActiveScale X100 Policy name Description Details Performance This policy provides the highest • Large files: 18/5. optimized, number of transactions per second. • Small files: 7/5 with a threshold of 0 to 8,388,608 bytes.
Page 127: Figure 10-19. Post-Login > Storage Policy
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-19. Post-Login > Storage Policy...
Page 128: Figure 10-20. Post-Login > Activescale
ActiveScale™ OS X100 Rackless Installation Guide If you enable telemetry collection, the system sends telemetry back to Quantum Support for analysis and support. Figure 10-20. Post-Login > ActiveScale m. Click Apply. A popup appears prompting you to confirm your chosen durability policy.
Page 129: Figure 10-22. Post-Login > Apply
ActiveScale™ OS X100 Rackless Installation Guide n. Click Continue to confirm. The Apply page appears with estimated time remaining. Note: If any errors appear on this page, click Show details, see Troubleshooting on page 160, and then click Retry. Upon successful completion of the post-login configuration wizard, the Go Live button appears. Figure 10-22.
Page 130: Multi-Site Deployments
A configuration wizard guides you through the pre-login configuration of the first system in a multi-site deployment, prompting you for network and other configuration settings you predetermined through your ActiveScale X100 Site Survey. Please have this document available for your reference.
Page 131: Summary Of Workflow
ActiveScale™ OS X100 Rackless Installation Guide 10.3.1 Summary of workflow 1. Bring a laptop with all data, cables, and certificates listed in What to bring with you to the data center on page 111. Do additional setup for a multi-site deployment on page 131.
Page 132: Create The Required Networks At Each Site
FTL410QE3C Configure the System Interconnects for your chosen uplink mode If you want an uplink mode other than mode 1 (the default), contact Quantum Support to configure the System Interconnects on all your systems. Important: This is an irreversible procedure and must be done by Quantum Support before initial bringup (in other words, before running the configuration wizard).
Page 133: Check Data Paths And Latency
– Site _Column3_StorageNetwork2 Tip: There are four networks required at each site for ActiveScale X100. . Figure 10-25. A multi-site ActiveScale X100 system 10.3.2.3 Check data paths and latency Your network/WAN infrastructure must ensure that the maximum round trip time (RTT) between each site is no more than 200ms.
Page 134: Create Uplinks
ActiveScale™ OS X100 Rackless Installation Guide • From site 1 to site 2: The network be connected to the network. .110 .120 • From site 1 to site 3: The network be connected to the network. .110 .130 • From site 2 to site 1: The network be connected to the network.
Page 135: Table 10-4. System Interconnect Uplink Ports
ActiveScale™ OS X100 Rackless Installation Guide • For uplink mode 1 (two individual 10G access ports (48,47) per System Interconnect): – Connect transceivers to ports 48 and 47 on each System Interconnect, on each system, at each site. • For uplink mode 2 (one 10G trunk port (48) per System Interconnect): –...
Page 136: Connect The System To Your Networks
Figure 10-27. System Node ports for Public Network 1 and Public Network 2 For racked ActiveScale X100 systems, feed the data center’s network cables through the cable routing brush strip on top of the rack: Figure 10-28. Network connection through top of rack Figure 10-29.
Page 137: Run The Pre-Login Configuration Wizard (Multi-Site Version)
At each site, the configuration wizard prompts you for the local network settings you predetermined through your ActiveScale X100 Site Survey. Please have this document available for your reference. Each site must use the same [multi-site] ActiveScale X100 Site Survey. After verifying network settings, the configuration wizard running at the primary site communicates with the secondary sites through their System Network 1 IP addresses and orchestrates the overall configuration process.
Page 138: Figure 10-30. Location Of System Nodes: Call Out # 4
ActiveScale™ OS X100 Rackless Installation Guide Tip: Pre-login configuration takes a minimum of 12 hours. Important: The systems at all sites must be completely powered on at this point. Important: The 10GbE cables from SFP+ ports 1 and 3 on each System Node must not be connected to your network(s) at this point, to avoid possible IP conflicts.
Page 139: Figure 10-31. System Node Eth2 Port
ActiveScale™ OS X100 Rackless Installation Guide The figure below illustrates the location of the eth2 port. Figure 10-31. System Node eth2 Port b. Give your laptop an IP address in the same range as System Node 1's default link local IP address for eth2, 169.254.140.1.
Page 140 ActiveScale™ OS X100 Rackless Installation Guide Tip: If the configuration wizard does not appear, you might be connected to the wrong System Node. Recheck your physical cabling. Tip: To find out which local site a configuration wizard is running on, look at its site icon in its upper left corner.
Page 141: Figure 10-33. Pre-Login > Site Configuration
Figure 10-33. Pre-Login > Site Configuration 5. On each configuration wizard, edit the fields on the Site Configuration page according to your predetermined values as recorded in your ActiveScale X100 Site Survey. Note: All fields are mandatory. 6. On each configuration wizard, click Next.
Page 142: Figure 10-35. Pre-Login > Site Review > Storage
ActiveScale™ OS X100 Rackless Installation Guide 7. On each configuration wizard, click each tab on the Site Review page to review your IP assignments. Warning: It is crucial that you correct any errors on this page. To make corrections, click Back and edit the settings. Warning: Once you navigate forwards to the Apply Progress page, you can no longer change Storage Network 1 and Storage Network 2 settings.
Page 143: Figure 10-36. Pre-Login > Inter Site Connectivity (Primary Site)
ActiveScale™ OS X100 Rackless Installation Guide d. Click the IPMI tab. The wizard displays the IPMI IP addresses for the system. Check each IP assignment to make sure it’s correct. Verify that the IPMI IP addresses do not conflict. 8. On each configuration wizard, click Next. The Inter Site Connectivity page appears on each configuration wizard.
Page 144: Figure 10-37. Pre-Login > Inter Site Connectivity (Secondary Sites)
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-37. Pre-Login > Inter Site Connectivity (secondary sites) 9. On each configuration wizard, click Next. The Global Review page appears. It shows the combined network configuration of the three sites. Figure 10-38. Pre-Login > Global Review (primary site)
Page 145: Figure 10-39. Pre-Login > Global Review (Secondary Sites)
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-39. Pre-Login > Global Review (secondary sites) 10. (Optional) On the configuration wizards at the secondary sites, review the settings and click Confirm to apply the settings, or Edit to make changes. 11. (Optional) On the configuration wizard at the primary site, wait for confirmation from the secondary sites.
Page 146: Figure 10-40. Pre-Login > Global Review > Click Apply
ActiveScale™ OS X100 Rackless Installation Guide address, you cannot run the access the system remotely to run the post-login configuration wizard. 13. On the configuration wizard at the primary site, click Apply to apply the settings. Warning: If you click Apply while a secondary site's settings are still being edited, the changes at that secondary site will be lost.
Page 147: Figure 10-42. Pre-Login > Apply Configuration
1000 connections with 100 parallel connections between 2 remote nodes. Each connection copies 1000 bytes. Contact Quantum Support. 15. Wait until the Pre-Configuration icon has a check mark and the Post-Login Configuration image is...
Page 148: Run The Post-Login Configuration Wizard (Multi-Site Version)
The post-login wizard guides you through the remaining configurable items. These steps should be executed by the primary system administrator only, at the primary site. Note: Quantum Support must confirm that BMC IPMI IP addresses are reachable (pingable) before starting the post login configuration phase. If any...
Page 149: Figure 10-44. Post-Login > Eula
ActiveScale™ OS X100 Rackless Installation Guide BMC addresses are not pingable Quantum Support must correct the problem (fix unreachable BMCs) first. Note: Complete the steps in Connect the system to your networks on page 136 before starting the post-login configuration.
Page 150: Figure 10-45. Post-Login > Configuration
ActiveScale™ OS X100 Rackless Installation Guide 2. Complete the EULA section. a. Review the EULA in its entirety. b. At the bottom of the EULA, type the Name and Title of the system administrator. c. To download a copy of the EULA, click Download. d.
Page 151 It is limited to 20 characters. You can hgstsupport change it at any time to allow/deny access to your system by Quantum Support. f. Paste in your SSL certificates for ActiveScale SM and the S3 interface. Note: SSL certificates must be in PEM format. Your PEM file must contain (in...
Page 152: Figure 10-46. Post-Login > S3
ActiveScale™ OS X100 Rackless Installation Guide If you enter an invalid SSL certificate, SSL will be disabled until you enter a valid certificate through ActiveScale SM. g. Type the IP address(es) of the DNS server(s) you want the system to connect to. h.
Page 153: Table 10-5. Storage Policies For A Multi-Site Activescale P100
ActiveScale™ OS X100 Rackless Installation Guide k. Enter your system’s geolocation information. Tip: The system applies Location settings to all three sites; you can change any site's settings through the ActiveScale SM later. Tip: Street Address, City, State, and Country are optional. Default Country is USA.
Page 154: Table 10-6. Storage Policies For A Multi-Site Activescale X100
Note: A multi-site deployment is a single global name-space across three sites. If you have two separate sites in a replication setup, see the storage policies for single site deployments. Table 10-6. Storage policies for a multi-site ActiveScale X100 Policy name Description...
Page 155: Figure 10-47. Post-Login > Durability Policy
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-47. Post-Login > Durability Policy...
Page 156: Figure 10-48. Post-Login > Activescale Cm
ActiveScale™ OS X100 Rackless Installation Guide m. Enable or disable telemetry collection (ActiveScale CM). If you enable telemetry collection, the system sends telemetry back to Quantum Support for analysis and support. Figure 10-48. Post-Login > ActiveScale CM Figure 10-49. Post-Login > Confirm...
Page 157: Figure 10-50. Post-Login > Apply
ActiveScale™ OS X100 Rackless Installation Guide n. Click Continue to confirm. The Apply page appears with estimated time remaining. Note: If any errors appear on this page, click Show details, see Troubleshooting on page 160, and then click Retry. Upon successful completion of the post-login configuration wizard, the Go Live button appears. Figure 10-50.
Page 158: Verify System Status
ActiveScale™ OS X100 Rackless Installation Guide the public network IP address for System Node 1 which you wrote down towards the end of the pre- configuration phase. 6. Log into ActiveScale SM with the username and the password you specified for admin admin Figure 10-51.
Page 159: Figure 10-53. The Dashboard For A Single Site Activescale X100
ActiveScale™ OS X100 Rackless Installation Guide Figure 10-53. The dashboard for a single site ActiveScale X100 This confirms the successful bringup of the system.
Page 160: Troubleshooting
To see details about the error, click Show details. The format of the details varies by step. Copy the text to a clipboard in case you need to send it to Quantum Support. To retry the operation, click Retry. Post login configuration gets stuck on setting the master Quantum Support must confirm that BMC IPMI IP encryption phrase.
Page 161 ActiveScale™ OS X100 Rackless Installation Guide Problem Recommended Action There is a power failure while the configuration wizard is Quantum Support must refer to internal documentation to running. Restart the Configuration Wizard After a Power Failure. The pre-login configuration wizard fails at the Apply...
Page 162 ActiveScale™ OS X100 Rackless Installation Guide...
Page 163: Installing Rack Seal Kits
ActiveScale™ OS X100 Rackless Installation Guide 11 Installing rack seal kits This section provides steps on how to install the rack seal kit. The rack seal kit (1EX0175) is a hardware upgrade that allows for the rack to be properly sealed in the event that third party liquid cooled doors are installed.
Page 164: Installing The Rack Seal Plate
ActiveScale™ OS X100 Rackless Installation Guide 11.1 Installing the rack seal plate Caution: Some components are heavy. Caution: Disconnect all power sources before servicing. Table 11-7. Rack seal plate installation overview Required tools Personnel None To install the rack seal plate: 1.
Page 165: Figure 11-55. Rack Seal Plate Cage Nuts
ActiveScale™ OS X100 Rackless Installation Guide Warning: Do not place fingers anywhere near the fan blades while powered on. 3. On the bottom of the rack, locate the screw holes closest to the rear of the rack. 4. Install a cage nut in each of the two holes. The right side is display in the figure below. The hole on the left side is located directly across from the hole on the right side, in the same position.
Page 166: Figure 11-58. Installing The Rear Fans
ActiveScale™ OS X100 Rackless Installation Guide 6. Using a #2 Phillips screwdriver, attach the rack seal plate to the holes with the cage nuts with the M5 screws. 7. From the rear of the rack, reinstall the rear fans on the bottom Storage Enclosure Basic. a.
Page 167: Installing Scale Up Kits
ActiveScale™ OS X100 Rackless Installation Guide 12 Installing scale up kits Scaling up the ActiveScale X100 is the process of adding sled columns to the Storage Enclosure Basics within the system to gain more drive capacity. At a minimum, each ActiveScale X100 contains at least one column of fully-populated sleds. That is, there is a sled populated with drives in the first, left-hand position of each of the six Storage Enclosure Basics in the system.
Page 168: Installing Sled Columns As Part Of Scale Up
ActiveScale™ OS X100 Rackless Installation Guide 12.1 Installing sled columns as part of scale up Caution: Some components are heavy. Caution: Disconnect all power sources before servicing. Table 12-8. Installing sled columns for scale up overview Required Tools Personnel None Note: Follow this procedure in its entirety on a single Storage Node-Storage Enclosure Basic pair, starting with the lowest pair.
Page 169: Figure 12-59. Unlocking The I/O Module
ActiveScale™ OS X100 Rackless Installation Guide SM to display the Storage Node as ONLINE before repeating this procedure on the next Storage Node-Storage Enclosure Basic pair. 1. Stop reads/writes to the Storage Node-Storage Enclosure Basic pair by gracefully powering down the Storage Node.
Page 170: Figure 12-60. Removing The I/O Module
ActiveScale™ OS X100 Rackless Installation Guide a. Slide the I/O module away from the chassis. Figure 12-60. Removing the I/O module 4. On the front of the leftmost sled blank, press the latch mechanism button and pull it until it is at a 45 degree angle.
Page 171: Figure 12-63. Removing The Sled Blank
ActiveScale™ OS X100 Rackless Installation Guide 5. Pull the sled blank out of the chassis. Figure 12-63. Removing the sled blank 6. Line the new populated sled up next to the last populated slot. 7. Slide the sled into the enclosure until fully seated. Figure 12-64.
Page 172: Provisioning The Newly Added Sleds On A Single Site System
ActiveScale™ OS X100 Rackless Installation Guide b. Plug the HD miniSAS cables into the HD miniSAS ports. c. Route the power cords through the I/O module handle. Important: Do not plug in the PSUs until the I/O module is fully seated. d.
Page 173: Figure 12-67. Starting A Scale Up
Monitor the status of the health check job in the Jobs pane. e. If the health check job has errors, stop. Contact Quantum Support for help. 2. Start the scale up wizard to provision newly populated sleds one by one.
Page 174: Figure 12-68. Scale Up: Password Verification
ActiveScale™ OS X100 Rackless Installation Guide 3. Enter the password for admin. Figure 12-68. Scale up: Password verification 4. Click Start Provisioning. Figure 12-69. Scale up: Start provisioning...
Page 175: Figure 12-70. Scale Up: Ready To Provision
ActiveScale™ OS X100 Rackless Installation Guide The wizard displays a screen with a checklist of steps that you should have completed already. 5. If you have completed the steps listed, click Provision. If you have not completed all steps in the checklist displayed, click Back to Let's Get Started, and complete them first.
Page 176: Provisioning The Newly Added Sleds On A Multi-Site System
ActiveScale™ OS X100 Rackless Installation Guide If the scale up job fails, click the icon in its Details column to see why it failed and suggestions on how to correct the problem. Follow the suggestions. 7. Check the dashboard to confirm that the added capacity is reflected in the Capacity tile. Figure 12-72.
Page 177 ActiveScale™ OS X100 Rackless Installation Guide imbalance is handled by the system transparently; it does not cause any disruption to application I/O, data durability, or failovers. Important: The system must be in a stable state before scaling up. The scale up job checks data safety levels when it starts.
Page 178: Figure 12-74. Starting A Scale Up
Monitor the status of the health check job in the Jobs pane. e. If the health check job has errors, stop. Contact Quantum Support for help. 2. Start the scale up wizard to provision newly populated sleds one by one.
Page 179: Figure 12-75. Scale Up: Password Verification
ActiveScale™ OS X100 Rackless Installation Guide 3. Enter the password for admin. Figure 12-75. Scale up: Password verification 4. Click Start Provisioning. Figure 12-76. Scale up: Start provisioning...
Page 180: Figure 12-77. Scale Up: Ready To Provision
ActiveScale™ OS X100 Rackless Installation Guide The wizard displays a screen with a checklist of steps that you should have completed already. 5. If you have completed the steps listed, click Provision. If you have not completed all steps in the checklist displayed, click Back to Let's Get Started, and complete them first.
Page 181: Figure 12-79. Scale Up: Confirmation On Dashboard
ActiveScale™ OS X100 Rackless Installation Guide If the scale ip job fails, click the icon in its Details column to see why it failed and suggestions on how to correct the problem. Follow the suggestions. 7. Check the dashboard to confirm that the added capacity is reflected in the Capacity tile. Figure 12-79.
Page 182: Installing Scale Out Kits
ActiveScale™ OS X100 Rackless Installation Guide 13 Installing scale out kits To scale out the system, you need to establish connections between the System Interconnects of the primary system and the System Interconnects of the secondary system, and run a wizard from the primary ActiveScale SM.
Page 183: Hardware Steps
ActiveScale™ OS X100 Rackless Installation Guide 13.1 Hardware steps Complete these hardware steps before proceeding to the software steps for scale out. On multi-site systems, complete all hardware steps at each site before proceeding on to the software steps. The steps below explain how to: •...
Page 184: Connecting The Cables Between The Systems
ActiveScale™ OS X100 Rackless Installation Guide Table 13-9. Parts needed for per system, per site Transceivers needed, per system, per site System Cables needed, per Uplink mode Quanti configuration system, per site Type Part number ActiveScale Mode 1 (two individual SFP+ Finisar 1EX0272 (there 2 10Gb cables per System...
Page 185: Cabling Two Systems
ActiveScale™ OS X100 Rackless Installation Guide Figure 13-81. Location of scale out ports: 49 (M1) and 51 (M3) 13.3.1 Cabling Two Systems Follow the instructions in this section if you are adding a second system (system 2) to your original system. The figure below shows the correct scale out cabling between two systems using an OM3 MPO Type-B female-to-female rack-to-rack cable.
Page 186: Opening Interconnect Ports
ActiveScale™ OS X100 Rackless Installation Guide Figure 13-83. Scale out cabling between 3 systems 1. Insert 40Gb transceivers into ports 49 (M1) and 51 (M3) of System Interconnects 1 and 2 on the new system, for a total of four transceivers plugged in. 2.
Page 187 ActiveScale™ OS X100 Rackless Installation Guide c. Run the following commands: (SiteN_System_Interconnect1) >en (SiteN_System_Interconnect1) #conf (SiteN_System_Interconnect1) (Config)#interface 0/49 (SiteN_System_Interconnect1) (Interface 0/49)#no shutdown (SiteN_System_Interconnect1) (Interface 0/49)#exit (SiteN_System_Interconnect1) (Config)#interface 0/51 (SiteN_System_Interconnect1) (Interface 0/51)#no shutdown (SiteN_System_Interconnect1) (Interface 0/51)#exit (SiteN_System_Interconnect1) (Config)#exit (SiteN_System_Interconnect1) #write memory confirm Config file 'startup-config' created successfully.
Page 188: Additional Steps For Multi-Site Configurations
ActiveScale™ OS X100 Rackless Installation Guide Connected to 169.254.110.200. Escape character is '^]'. User:admin Password: d. Run the following commands: (SiteN_System_Interconnect1) >en (SiteN_System_Interconnect1) #conf (SiteN_System_Interconnect1) (Config)#interface 0/49 (SiteN_System_Interconnect1) (Interface 0/49)#no shutdown (SiteN_System_Interconnect1) (Interface 0/49)#exit (SiteN_System_Interconnect1) (Config)#interface 0/51 (SiteN_System_Interconnect1) (Interface 0/51)#no shutdown (SiteN_System_Interconnect1) (Interface 0/51)#exit (SiteN_System_Interconnect1)
Page 189: Software Steps
Quantum Support to update the host names of all components on all your systems before you follow this procedure. Before following these steps, complete the hardware steps in the ActiveScale X100 Installation Guide at each site. You can only scale out incrementally (one new system at a time at each site).
Page 190: Figure 13-84. Starting A Scale Out
ActiveScale™ OS X100 Rackless Installation Guide important if you purchased multiple systems for an initial install. Systems that have been running for some time may report a lowered data safety after a scale out. You must resolve any data safety issues before attempting to scale out. If the data safety of the system is not optimal or there are failed drives, fix the issues by replacing the drives before starting this procedure.
Page 191: Figure 13-85. Sample Pop-Up With Results Of System Scan
– If the wizard indicates that there is a version mismatch, click Close. Update the ActiveScale OS on the existing system(s) and start the wizard again. For upgrade help, contact Quantum Support. – If the wizard finds no problems, click Continue. The wizard displays the network settings.
Page 192: Figure 13-87. Scale Out: Click Proceed To Apply Network Settings
ActiveScale™ OS X100 Rackless Installation Guide Tip: You can change the 4th octet of the new system’s Public Network IP addresses and you can change Storage Network addresses. System Network addresses are carried forward from the existing system(s), so you cannot change them.
Page 193: Figure 13-89. Scale Out: Confirmation On Dashboard
ActiveScale™ OS X100 Rackless Installation Guide If the scale out job succeeds, ActiveScale SM displays a pop-up prompting you to change the hgstsupport password for the entire system. The new system has a different hgstsupport password than the existing system(s). Therefore, best practice is to set a common hgstsupport password for the entire system.
Page 194: Post-Requisites
ActiveScale™ OS X100 Rackless Installation Guide 8. Check Resources to confirm that the new system’s components are displayed with correct host names. For example, for a multi-site deployment, System Node 3 on the second system at site 1 should have the host name Site1-R02-SG03.
Page 195: Installing System Expansion Node Kits
System Nodes allow you to increase system performance with your current storage capacity. You can add up to three System Expansion Node kits (three additional System Nodes) to each ActiveScale X100 base system. Multi-site deployments can support up to 21 System Expansion Nodes.
Page 196: System Expansion Node Kit Requirements
ActiveScale™ OS X100 Rackless Installation Guide 14.1 System Expansion Node kit requirements Before purchasing a System Expansion Node kit, ensure that your ActiveScale X100 system meets the requirements in this section. 14.1.1 Public Network IP address requirements System Expansion Nodes in the same local rack must be in the same subnet.
Page 197: Installing System Expansion Node Kits
ActiveScale™ OS X100 Rackless Installation Guide 1. Remove the cables and mounting kit. 2. Remove the System Expansion Node. 3. Inspect each item in the box for damage. Repeat this process for each System Expansion Node kit. 14.3 Installing System Expansion Node kits System Nodes and System Expansion Nodes use the same installation procedure.
Page 198: Installing The 1U Rail Kit
ActiveScale™ OS X100 Rackless Installation Guide Figure 14-1. System Expansion Node rack locations 14.3.1 Installing the 1U rail kit To install the rails for the System Expansion Node:...
Page 199: Figure 14-2. Expand The Outer Rail
ActiveScale™ OS X100 Rackless Installation Guide 1. Attach the outer rails to the rack. Note: Verify that you are installing the correct rail on each side of the rack. The rear of each rail is marked with “rear”. a. Extend the outer rail enough that it extends between the two vertical rails of the rack. Figure 14-2.
Page 200: Figure 14-4. Rail Attaching To Front Vertical Rail
ActiveScale™ OS X100 Rackless Installation Guide e. Extend the outer rail forward and insert the pegs into the front vertical rail. Figure 14-4. Rail attaching to front vertical rail f. Extend the inner rail to its full length. g. Remove the inner rail by sliding the white clip with a rounded edge forward. Note: Be cautious leaving the outer rails extending out of the rack.
Page 201: Installing A System Expansion Node Into The Rack
ActiveScale™ OS X100 Rackless Installation Guide 14.3.2 Installing a System Expansion Node into the rack Important: Install components into the rack from bottom to top. Important: The System Expansion Node weighs 27 lbs (12.2 kg), take precautions when lifting. To install a System Expansion Node: 1.
Page 202: Installing System Expansion Node Kits In Multi-Site Systems
A multi-site system can support up to 21 System Expansion Nodes. System Expansion Nodes do not need to be mirrored across multiple sites. Table 14-4. Multi-site example configuration System Expansion Nodes per Rack ActiveScale X100 system Primary rack Scale out rack 1 Scale out rack 2 Scale out rack 3...
Page 203: Installing The System Expansion Node Pdu Kit
System Expansion Node kits on page 195. To install a third PDU into an ActiveScale X100 system: 1. From the rear of the rack, feed the plug through the opening in the top of the rack. Ensure the plug is draped over the rack in a safe location and will not fall back through the hole.
Page 204: Three-Phase Across Two Pdus
ActiveScale™ OS X100 Rackless Installation Guide Note: Plug Storage Enclosure Basics and their corresponding Storage Nodes into the same segment of the PDU. 14.6.1.1 Three-phase across two PDUs Table 14-5. Three-phase across two PDUs - PDUs 1 and 2 Branch ZX Plug Current (A) Component...
Page 205: Three-Phase Across Three Pdus
ActiveScale™ OS X100 Rackless Installation Guide 14.6.1.2 Three-phase across three PDUs Table 14-6. Three-phase across three PDUs - PDU 1 Branch ZX Plug Current (A) Component Port Time on (s) C-13 2.02 System Expansion Node 3 28 C-13 1.15 Storage Node 6 C-13 Storage Enclosure Basic 6 25 C-13...
Page 206 ActiveScale™ OS X100 Rackless Installation Guide C-13 Storage Enclosure Basic 4 15 C-13 2.02 System Node 2 C-13 1.06 System Interconnect 1 10.55 Total Branch XY Plug Current (A) Component Port Time on (s) C-13 2.02 System Expansion Node 1 8 C-13 1.15 Storage Node 1...
Page 207: Programming The Pdus
ActiveScale™ OS X100 Rackless Installation Guide Table 14-8. Three-phase across three PDUs - PDU 3 Branch ZX Plug Current (A) Component Port Time on (s) C-13 2.02 System Expansion Node 3 28 C-13 1.15 Storage Node 5 C-13 1.16 System Node 3 C-13 Storage Enclosure Basic 5 23 C-13...
Page 208: Connecting To The Pdu With An Ethernet Port
ActiveScale™ OS X100 Rackless Installation Guide • Baud: 9600 • Data Bits: 8 • Parity: None • Stop Bits: 1 • Flow Control: None 14.6.2.2 Connecting to the PDU with an Ethernet port The PDU is also equipped with an RJ45 10/100Base-T Ethernet port. Use this connection to access the PDU firmware CLI with Telnet.
Page 209: Three-Phase Pdu Programming With Three Pdus
ActiveScale™ OS X100 Rackless Installation Guide 14.6.2.4 Three-phase PDU programming with three PDUs • PDU 1 show system show units set unit name A PDU-1 set access prompt Switched CDU: set outlet name AA1 UNUSED1 set outlet name AA2 UNUSED2 set outlet name AA3 UNUSED3 set outlet name AA4 JBOD1 set outlet name AA5 CSN1...
Page 210 ActiveScale™ OS X100 Rackless Installation Guide set outlet extondelay AA14 0 set outlet extondelay AA15 0 set outlet extondelay AA16 50 set outlet extondelay AA17 0 set outlet extondelay AA18 20 set outlet extondelay AA19 30 set outlet extondelay AA20 0 set outlet extondelay AA21 0 set outlet extondelay AA22 0 set outlet extondelay AA23 0...
Page 211 ActiveScale™ OS X100 Rackless Installation Guide set outlet name AA25 JBOD6 set outlet name AA26 CSN5 set outlet name AA27 CSN6 set outlet name AA28 UNUSED28 set outlet name AA29 UNUSED29 set outlet name AA30 UNUSED30 set outlet extondelay AA1 0 set outlet extondelay AA2 0 set outlet extondelay AA3 10 set outlet extondelay AA4 20...
Page 212 ActiveScale™ OS X100 Rackless Installation Guide set outlet name AA6 JBOD2 set outlet name AA7 CSN2 set outlet name AA8 SEN1 set outlet name AA9 UNUSED9 set outlet name AA10 UNUSED10 set outlet name AA11 UNUSED11 set outlet name AA12 UNUSED12 set outlet name AA13 JBOD3 set outlet name AA14 UNUSED14 set outlet name AA15 JBOD4...
Page 213: Programming The System Interconnects
ActiveScale™ OS X100 Rackless Installation Guide set outlet extondelay AA26 50 set outlet extondelay AA27 0 set outlet extondelay AA28 30 set outlet extondelay AA29 0 set outlet extondelay AA30 0 set outlet seqdelay 0 set dhcp staticfallback disabled reboot ALL 14.7 Programming the System Interconnects After cabling the System Expansion Nodes, log into the System Interconnect and open ports 38 (for System Expansion Node 1), 40 (for System Expansion Node 2) and 42 (for System Expansion Node 3).
Page 214 ActiveScale™ OS X100 Rackless Installation Guide 1. Connect an Ethernet cable from your laptop to port 44 on System Interconnect 1. 2. Configure your computer to be on the same network as the System Interconnect using the following values: – Management Port: 192.168.123.0/24 –...
Page 215: Powering On The System Expansion Node
14.9 Software steps for adding a System Expansion Node kit Before following these steps, complete the hardware steps in the /ActiveScale X100 Installation Guide. You can add one new System Expansion Node at a time to only one system at any one site.
Page 216: Figure 14-7. Starting A System Expansion Node Job
ActiveScale™ OS X100 Rackless Installation Guide Warning: Do not start a log collection job while a System Expansion Node job is running. 1. Start the system expansion wizard. Important: On multi-site deployments, log into the GUI from the on each sites System Node to initiate the wizard.
Page 217: Figure 14-8. Selecting Which System The New System Expansion Node Is Attached To
ActiveScale™ OS X100 Rackless Installation Guide Select the system which the new System Expansion Node is attached to, and click Next. Figure 14-8. Selecting which system the new System Expansion Node is attached to The System Expansion Node wizard starts. ActiveScale OS disables the DHCP server on the System Nodes and scans for the new System Expansion Node’s link local IP addresses.
Page 218: Figure 14-9. System Expansion Node: Summary Of Scan
2. For each site, validate the network settings in each tab against your settings as specified in your ActiveScale X100 Site Survey, and/or change the Storage Network settings. Tip: You can change the 4th octet of the new system’s Public Network IP addresses.
Page 219: Figure 14-10. System Expansion Node: Click Proceed To Apply Network Settings
ActiveScale™ OS X100 Rackless Installation Guide Figure 14-10. System Expansion Node: Click Proceed to apply network settings The wizard notifies you to check the System Expansion job on the Jobs page. 5. Navigate to the Jobs page, and wait until the System Expansion job indicates success or failure. The Jobs page displays the progress of the System Expansion job.
Page 220: Figure 14-12. System Expansion Node: Job Success
ActiveScale™ OS X100 Rackless Installation Guide Figure 14-12. System Expansion Node: Job success 6. Log out of the GUI and log back in to see the new system node and check the dashboard to confirm that the new system node is displayed in the Resources tile with the correct name. For example, for a multi-site deployment, System Expansion Node 3 on the second system at site 1 should have the host name Site1-R02-SEN03.
Page 221: Figure 14-14. System Expansion Node: Confirmation On Resources Pane
ActiveScale™ OS X100 Rackless Installation Guide Figure 14-14. System Expansion Node: Confirmation on Resources pane 7. If you are using NFS client failover, assign a virtual IP address to the new System Expansion Node. For more information, see the ActiveScale OS Administrator Guide. You have now completed the addition of the System Expansion Node.
Page 222: System Specifications
ActiveScale™ OS X100 Rackless Installation Guide 15 System specifications This section provides the specifications for the ActiveScale X100. Topics: • System specification summary on page 223 • Hard disk drive specifications on page 224 • Management Interconnect specifications on page 226 •...
Page 223: System Specification Summary
ActiveScale™ OS X100 Rackless Installation Guide 15.1 System specification summary The following table is a summary of specifications relevant to the ActiveScale X100. Condition (fully configured) Non-operating Operating Altitude -984 ft to 39,3711 ft -984 ft to 10,000 ft (-300 m to 12,000 m) (-300 m to 3048 m) •...
Page 224: Hard Disk Drive Specifications
3.The minimum system weight does not include the rack and PDUs 15.2 Hard disk drive specifications The following tables list the specifications for the Quantum Corporation qualified hard disk drives contained within the System Nodes, Storage Nodes, and Storage Enclosure Basics Table 15-9.
Page 225: Table 15-10. 10 Tb Hard Disk Drive Specification Summary
• Four per Storage Node Replacement part number 1EX0222 Type SATA 1.Only hot swappable after decommissioning. Table 15-10. 10 TB hard disk drive specification summary Condition Specification Quantum Corporation Model Ultrastar He10 ® Capacity 10 TB Dimensions • Width—4 +/-0.0098 in (101.6 +/-0.25 mm) •...
Page 226: Management Interconnect Specifications
ActiveScale™ OS X100 Rackless Installation Guide Table 15-12. 14 TB hard disk drive specification summary Condition Specification Quantum Corporation Model Ultrastar HD HC500 ® Capacity 14 TB Dimensions • Width—4 +/-0.0098 in (101.6 +/-0.25) mm • Depth—5.78 (147 mm) • Height—1.02 in (26.1 mm)
Page 227: Pdu Specifications
ActiveScale™ OS X100 Rackless Installation Guide Table 15-13. Management Interconnect Specifications Condition Specification Dimensions • Width—8.23 in (209 mm) • Depth—9.84 in (250 mm) • Height—1.62 in (41.25 mm) Hot swappable? Operating relative humidity 10% to 90% non-condensing Operating temperature 32°F to 122°F (0°C to 50°C) Quantity (per system) Rack units (U)
Page 228: Power Cords
• The power supply cord(s) is / are the main disconnect device to AC power. The socket outlet(s) must be near the equipment and readily accessible for disconnection. 15.5 Rack specifications The following table lists the rack specifications for the racked ActiveScale X100. Rackless versions of the ActiveScale X100 use customer-supplied racks.
Page 229: Table 15-16. Rack Specifications
ActiveScale™ OS X100 Rackless Installation Guide Figure 15-15. Rack dimensions Table 15-16. Rack specifications Condition Specification Bracing Basic bracing, using the L-brackets, is standard with the shipping materials and used to brace the system to the data center floor. Doors Standard, single leaf, top and bottom vented, front and rear doors are shipped with the system Power cord route management...
Page 230: Solid State Drive Specifications
ActiveScale™ OS X100 Rackless Installation Guide 15.6 Solid state drive specifications The following table lists the Quantum Corporation qualified solid state drives (SSD) contained within the System Nodes and Storage Nodes. Table 15-17. 480 GB solid state drive specification summary...
Page 231: Storage Node Specifications
ActiveScale™ OS X100 Rackless Installation Guide Table 15-19. Storage Enclosure Specifications Condition Specification Operating relative humidity 8% to 90% non-condensing Operating temperature 41° to 104°F (5°C to 40°C) Quantity Rack units Relative humidity gradient 30% per hour maximum Temperature de-rating 33.8°F per 984.2 ft above 9842.5 ft (1°C per 300 m above 3000 m) Temperature gradient...
Page 232: System Node Specifications
ActiveScale™ OS X100 Rackless Installation Guide Condition Specification Quantity (per system) Rack Units (U) Weight (individual) 20 lbs (9 kg) Weight (total for all System Interconnects) 40 lbs (18 kg) 15.10 System Node specifications The following table lists the system specifications for an individual System Node. Condition Specification Dimensions...
Page 233: Recommended Torque Of Machined Fasteners
ActiveScale™ OS X100 Rackless Installation Guide 16 Recommended torque of machined fasteners The following list is the recommended torque of the machined fasteners being used during replacement or installation of ActiveScale X100 components. Table 16-21. Recommended torque of machined fasteners (rack components) Screw size Torque n-m Torque in.-lbs...
Page 234 ActiveScale™ OS X100 Rackless Installation Guide...
Page 235: About The Cord Retention Bale
The cord retention bale is adjustable to the size of different approved power cords. The retention bale should already be set correctly for the power cables supplied with the ActiveScale X100. You only need to adjust the cord retention bale if you are not using the Quantum Corporation-supplied cables.
Page 236: Figure 17-17. Adjustment Holes For Cord Retention Bale
ActiveScale™ OS X100 Rackless Installation Guide 3. Locate the preferred set of holes. Note: There are five sets of holes. Position one located at the top and position five located at the bottom. Figure 17-17. Adjustment holes for cord retention bale 4.
Page 237 ActiveScale™ OS X100 Rackless Installation Guide 6. Before you install the PSU into the I/O module, plug in an approved power cord. (The molding on non-approved power cords may not fully seat into the PSU.) 7. Verify that the approved power code fits with the new location of the cord retention bale. 8.
Page 238 ActiveScale™ OS X100 Rackless Installation Guide...
Page 239: Host Connectivity For The Storage Enclosure Basic
18 Host connectivity for the Storage Enclosure Basic Connect the Storage Enclosure Basic to the Storage Node, using high quality miniSAS HD cables. The following table displays the list of power cables approved by Quantum Corporation for the Storage Enclosure Basic: Table 18-22.
Page 240 ActiveScale™ OS X100 Rackless Installation Guide...
Page 241: About Activescale X100 Racks
ActiveScale™ OS X100 Rackless Installation Guide 19 About ActiveScale X100 racks The ActiveScale X100 system is designed to be integrated into the user's own rack mounting solution and does not come installed in an Quantum Corporation rack. Therefore, this section describes what is required of a rack mounting solution in order to accommodate the physical dimensions and performance characteristics of the product.
Page 242: Rack Requirements
19.2 Airflow considerations Ensure that both the front and rear of the ActiveScale X100 stay clear of any materials that may block or disrupt the airflow in any way. Disrupting the airflow can cause the system to overheat which may affect performance or cause damage to the system.
Page 243: Table 19-25. Airflow Requirements
ActiveScale™ OS X100 Rackless Installation Guide • Controlled air conditioners that are functional and can sufficiently maintain specified system operating temperatures should be located in the facility where the system will be installed. • The airflow in and out of the equipment must not be restricted. Table 19-25.
Page 244 ActiveScale™ OS X100 Rackless Installation Guide...
Page 245: Pdu Specifications
20 PDU specifications This appendix defines the requirements for the PDUs to be used in the ActiveScale X100 system rack. It is not intended to be a full description of the PDU selected. The PDU may have additional features not required by this application.
Page 246: Pdu Requirements, Common
PDU where one PDU cannot provide enough power for the ActiveScale X100 system. For these power configurations, up to two power connections will be used for each “source” of the system.
Page 247: Mechanical Requirements
20.2 Mechanical requirements 20.2.1 Redundancy The PDUs selected must have at least 34 receptacles available for ActiveScale X100 components. Preferably, these would be split into 2, redundant, PDUs, to protect the system from PDU or power failure. Each component would have one connection to each PDU.
Page 248: Monitoring
PDU monitoring is a requirement in your environment. 20.3.1 Local monitoring The monitoring requirement is optional. However, Quantum Corporation recommends that each PDU shall include local (on board) indicators of the status of each branch circuit. These will show the following information: Branch Circuit Protection Device State:Closed circuit:Open circuit.
Page 249: Safety
Storage Nodes 3-5 seconds for each device For an example of the exact programming sequence used by Quantum Corporation power supplies, refer to the cabling section of the ActiveScale X100 Support Guide. 20.4.1 Safety The PDU used shall comply with the safety standards of the country that rack is installed in.
Page 250: 3-Phase Delta, 208V, 24A, Na, Japan
ActiveScale™ OS X100 Rackless Installation Guide 20.5.1 3-phase delta, 208V, 24A, NA, Japan Table 20-33. Input power configuration Number PDUs required by system including redundancy 2 Input configuration: 3-phase delta Nominal input voltage (line-to-line): 208VAC Input voltage operating range: 200VAC-220VAC Nominal frequency: 60Hz Table 20-34.
Page 251 ActiveScale™ OS X100 Rackless Installation Guide Table 20-39. Dimensions and weights (continued) Height 70.5 in. / 1791 mm Depth 2.2 in / 55 mm Weight 18 lbs. / 8.2 kg...
Page 252: 3-Phase Delta, 208V, 48A, Na
ActiveScale™ OS X100 Rackless Installation Guide 20.5.2 3-phase delta, 208V, 48A, NA Table 20-40. Input power configuration Number PDUs required by system including redundancy 2 each Input configuration: Three-phase delta Nominal input voltage (line-to-line): 208VAC Input voltage operating range: 180VAC-220VAC Nominal frequency: 60Hz Table 20-41.
Page 253 ActiveScale™ OS X100 Rackless Installation Guide Table 20-46. Dimensions and weights (continued) Height 70.5 in. / 1791 mm Depth 2.2 in / 55 mm Weight 18 lbs. / 8.2 kg...
Page 254: 3-Phase Wye, 230V, 16A, Europe, Global
ActiveScale™ OS X100 Rackless Installation Guide 20.5.3 3-phase WYE, 230V, 16A, Europe, Global Table 20-47. Input power configuration Number PDUs required by system including redundancy 2 Input configuration: 3-phase WYE Nominal input voltage (line-to-neutral): 230VAC Input voltage operating range: 220VAC-240VAC Nominal frequency: 50Hz Table 20-48.
Page 255 ActiveScale™ OS X100 Rackless Installation Guide Table 20-53. Dimensions and weights (continued) Height 70.5 in. / 1791 mm Depth 2.2 in / 55 mm Weight 18 lbs. / 8.2 kg...
Page 256: Single-Phase 220V, 24A, Na
ActiveScale™ OS X100 Rackless Installation Guide 20.5.4 Single-phase 220V, 24A, NA Table 20-54. Input power configuration Number PDUs required by systemincluding redundancy 4 Input configuration: 1-phase Nominal input voltage (line-to-neutral): 208VAC Input voltage operating range: 200VAC-240VAC Nominal frequency: 60Hz Table 20-55. Input current/power Input current, steady state available: 24A, NA de-rated Input current, peak available:...
Page 257 ActiveScale™ OS X100 Rackless Installation Guide Table 20-60. Dimensions and weights (continued) Height 69 in. / 1753 mm Depth 2.25 in / 57 mm Weight 18 lbs. / 8.2 kg...
Page 258: 1-Phase 230V, 32A, Europe, Global
ActiveScale™ OS X100 Rackless Installation Guide 20.5.5 1-phase 230V, 32A, Europe, global Table 20-61. Input power configuration Number PDUs required by system including redundancy 4 Input configuration: Single-phase Nominal input voltage (line-to-neutral): 230VAC Input voltage operating range: 220VAC-240VAC Nominal frequency: 50Hz Table 20-62.
Page 259 ActiveScale™ OS X100 Rackless Installation Guide Table 20-67. Dimensions and weights (continued) Height 69 in. / 1753 mm Depth 2.25 in / 57 mm Weight 18 lbs. / 8.2 kg...
Page 260 ActiveScale™ OS X100 Rackless Installation Guide...
Page 261: How To Read Cable Labels
ActiveScale™ OS X100 Rackless Installation Guide 21 How to read cable labels Each data cable in the system contains a label at both ends to determine where to connect the cables into a component. The image below provides the necessary information to understand the connections for each particular cable.
Page 262: Figure 21-20. Components And Port Identification
ActiveScale™ OS X100 Rackless Installation Guide Figure 21-20. Components and port identification...
Page 263: Figure 21-21. Activescale X100 Cable Wiring Key
ActiveScale™ OS X100 Rackless Installation Guide Figure 21-21. ActiveScale X100 cable wiring key...
Page 264 ActiveScale™ OS X100 Rackless Installation Guide...
Page 265: Contacting Quantum
ActiveScale™ OS X100 Rackless Installation Guide Contacting Quantum Contacting Quantum For further assistance, contact the Quantum Contact Support Center. Region Support Contact North America 1-800-284-5101 (toll free) +1-720-249-5700 EMEA +1-800-7826-8888 (toll free) +49 6131 324 185 Asia Pacific +800-7826-8887 (toll free)

Quantum ActiveScale X100 Installation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Quantum ActiveScale X100

Summary of Contents for Quantum ActiveScale X100
