- Page 1 Keypad with touch keys INT-KSG2R Firmware version 2.02 USER MENU – PERFECTA 64 M int-ksg2r_op_en 02/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. Hereby, SATEL sp. z o.o. declares that the radio equipment type INT-KSG2R is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.satel.pl/ce...
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ........................2 2. LED indicators ........................2 3. Display ..........................3 4. Keys ..........................4 5. Using the touch keys ......................4 6. Macro commands ......................7 7. Keypad lock ........................7... -
Page 4: Introduction
SATEL 1. Introduction Thank you for choosing this product by SATEL. Familiarize yourself with this manual before you start using the keypad. This manual describes the keypad components and their features. For description on how to use the keypad for control panel operation, please refer to the user manual of the control panel to which the keypad is connected. -
Page 5: Display
SATEL INT-KSG2R Information about the armed status may be hidden after a time period defined by the installer. The trouble information is hidden after arming. The installer defines if the trouble information is hidden after just one of the partitions is armed in any mode or after all partitions are armed in full mode. -
Page 6: Keys
4 keys used to run macro commands (see: “Macro commands” p. 7) Availability of the functions depends on the keypad settings. The functions of keys in the user menu are described in the PERFECTA 64 M control panel user manual. - Page 7 SATEL INT-KSG2R Touch Touch the key with your finger. Touch and hold Touch the key and hold for 3 seconds. Swipe up Touch the keys area and slide your finger up to: scroll up the list, move the cursor up or left (depending on the function), ...
- Page 8 INT-KSG2R SATEL Swipe down Touch the keys area and slide your finger down to: scroll down the list, move the cursor down, change the letter case when editing, exit the graphic mode. Swipe right Touch the keys area and slide your finger right to: ...
-
Page 9: Macro Commands
SATEL INT-KSG2R Swipe left Touch the keys area and slide your finger left to: exit the submenu, move the cursor left, enter the graphic mode. 6. Macro commands The macro command is a sequence of actions to be performed by the control panel. - Page 10 INT-KSG2R SATEL Notes .......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
