ITech IT8500+ Series Manual page 31

69. Set/Enquire autotest chain file.（DEH/DFH）
st
1 byte
th
2 byte
th
3 byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
70. Save/Recall autotest file.( DEH/DFH)
st
1 byte
2 th byte
th
3 byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
71. Set/Enquire Von mode.（0EH/0FH）
st
1 byte
th
2 byte
th
3 byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
72. Set/Enquire Von value.( 10H/11H)
st
1 byte
th
2 byte
th
3 byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
NOTE
Receiving one frame command and verify them
If verify sum is wrong, return the parameter 90H
If setting parameter is wrong or over brim, return parameter A0H.
If command is not enforce, return to parameter B0H
If command is invalid, return to parameter C0H
Start bit ( AAH )
Address (0—31,0XFF)
Command（DEH/DFH）
Chain file number
(0 repersents chain no file)
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command（E0H/E1H）
File number
(0 repersents do not save)
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command（0EH/0FH）
Von mode(0:Living 1:Latch)
System reserve
Check sum
Start bit ( AAH )
Address (0—31,0XFF)
Command（10H/11H）
Von value(
Lower bytes are in the former location, higher bytes are in
)
the later location
System reserve
Check sum
31
