ITech IT8500+ Series Manual page 20

th
4 byte
th th
From 5 to 25 byte
th
26 byte
26. Send a trigger signal to trigging the electronic load. (5AH)
st
1 byte
2 nd byte
rd
3 byte
th th
From 4 to 25 byte
th
26 byte
27. Saving / Recall user's setting value in appointed memory area for recall.
(5BH/5CH)
st
1 byte
nd
2 byte
3 rd byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
28. Selecting / Getting FIXED/SHORT/TRAN/LIST/ BATTERY function mode.
(5DH/5EH)
st
1 byte
nd
2 byte
3 rd byte
th
4 byte
th th
From 5 to 25 byte
th
26 byte
29. Read input voltage, current, power and relative state. (5FH)
st
1 byte
nd
2 byte
rd
3 byte
th th
From 4 to 7 byte
th th
From 8 to 11 byte
th th
From 12 to 15 byte
th
16 byte
th th
From 17 to 18 byte
th th
From 19 to 25 byte
th
26 byte
Trigger mode (0:Manual,1: External,2:Bus,3:Hold)
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command（5AH）
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command（5BH/5CH）
Storing area
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command（5DH/5EH）
Work mode (0:FIXED,1:SHORT, 2:TRANSITION,3:LIST,4: BATTERY)
System reserve
Sum code
Start bit ( AAH )
Address (0—31,0XFF)
Command （5FH）
Actual input voltage value (Lower bytes are in the front location, higher bytes are
in the later location)
Actual input current value (Lower bytes are in the front location, higher bytes are
in the later location)
Actual input power value (Lower bytes are in the front location, higher bytes are
in the later location)
Operation state register
Demand state register
System reserve
Sum code
