- Page 1 Operating instructions Absolute encoders RM8x / RMx4xx with SSI interface...
-
Page 2: Table Of Contents
Contents 1 Preliminary note 3 11 Symbols used 3 2 Safety instructions 3 3 Functions and features 4 4 Installation 4 41 Installation solid shaft encoder (synchro flange) 4 42 Installation hollow shaft encoder 5 5 Electrical connection 5 51 Laying the cable 5 52 Standard wiring 6... -
Page 3: Preliminary Note
1 Preliminary note 1.1 Symbols used • An instruction is indicated by "►". Example: ► Mount the unit as shown. • A reaction to the action is indicated by ">" Example: > Yellow LED is lit Important note Non-compliance can result in malfunction or interference 2 Safety instructions •... -
Page 4: Functions And Features
3 Functions and features The encoder converts rotary movements into digital numerical vales Each revolution and each angular position of the revolutions is provided as a numerical value These values allow angular movements to be measured and positions and number of revolutions to be determined •... -
Page 5: 42 Installation Hollow Shaft Encoder
4.2 Installation hollow shaft encoder ► Place the clamping nut on the encoder ► Slip the encoder onto the shaft (min 10 mm) and fix the stator coupling by means of one M3 screw ► Tighten the screws of the clamping nut ►... -
Page 6: 52 Standard Wiring
► Connect and ground the encoder housing, the connector/ terminal box and the evaluation electronics via the screen ► Connect the device according to the indications on the type label 5.2 Standard wiring white / pin 3 brown / pin 1 green / pin 2 yellow / grey / pin 5... -
Page 7: 613 Level Of The Control Inputs
The operation of the unit is maintenance-free It is not possible to repair the unit After use dispose of the unit in an environmentally friendly way in accordance with the applicable national regulations Technical data and further information at wwwifmcom...
