Technical data
12.1.3 Dimensions UNIGATE® IC-DeviceNet (new DNL-hardware)
The pins of UNIGATE® IC are arranged with a grid spacing of 2.54 mm.
In case you intend to use other fieldbus ICs, the maximum overall height of
pins) has to be taken into consideration.
12.2 Technical data UNIGATE® IC-DeviceNet
Characteristics
Supply voltage
Interface
Physical separation
-fieldbus-side
Fieldbus-ID
Fieldbus-baud rate
Product code
I/O-sizes
UART-baud rate
Fieldbus data format
Technology
Others
Dimensions
Installation
Weight
Operating temperature
Storage / transport temperature -40°C..+125°C
Built-in position
32
Explanation
5 V ± 5 %, max. 75 mA DC
2 UART interfaces, 1 synchronous serial interface
Standard
Adjustable via script
Up to 500 Kbaud (adjustable via script)
Adjustable via script
Adjustable via script at present (0...255 bytes)
Up to 625 Kbaud (adjustable via script)
Group 2 slave
SJA1000
Polling
E.g. digital I/Os, analogue signals, shift registers
LEDs, switches tec. can be connected externally
45 x 9.5 x 25 mm (WxHxD), old hardware: 45 x 16 x 25 mm (WxHxD)
32 DIL
15 G
-40°C ..+85°C
Any
Instruction manual UNIGATE
Deutschmann Automation GmbH & Co. KG
®
IC - DeviceNet V. 2.7
≤
20 mm (including
