10 Error handling at UNIGATE IC

A distinction can be made between two categories of system-errors:
Serious errors (1-4): In this case, the Gateway must be switched off and switched back on again.
If the error occurs again, the Gateway must be exchanged and returned for repair.
Warnings (6-15): These warnings are displayed for one minute simply for information purposes
and are then automatically reset. If such warnings occur frequently, please inform After-Sales
Service.
The system-error can be read-out via the Script.
Error no. Error description
0 Reserved
1 Hardware fault
2 EEROM error
3 Internal memory error
4 Fieldbus hardware error or wrong Fieldbus-ID
5 Script error
6 Reserved
7 RS-transmit buffer overflow
8 RS-receive buffer overflow
9 RS timeout
10 General fieldbus error*
11 Parity-or frame-check-error
12 Reserved
13 Fieldbus configuration error
14 Fieldbus data buffer overflow
15 Reserved
Table 1: Error handling at UNIGATE IC
*) The system-error 10 is always displayed when one of the following errors appears:
Error
DUP_MAC_ERROR
RX_QUEUE_OVERRUN
TX_QUEUE_OVERRUN
IO_SEND_ERROR
CAN_BUS_OFF
CAN_OVERRUN
EXPL_CNXN_TIMEOUT 1)
IO_CNXN_TIMEOUT
IO_CNXN_DELETE
DNS_RESET
DNS_BUS_SENSE_ERROR
1) Timeout = Expected Packed Rate * 4!
With the Script command "Get (DetailErrorCode, w_Error)" the above value can be read out and
with it it can be exactly determined, what error was the actuator.
7.10.10
Error value
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
