AML Oceanographic AML-6 RT User Manual page 8

copper alloy to prevent biofouling (optional upgrade) but the default configuration uses stainless
steel.
Specifications:
Model 500m
Depth rating 500 meters / 1640 feet
Material Acetal, 316 stainless steel,
titanium, polycarbonate
Data storage 30 GB
Software Sailfish
Communication RS-232 or RS-485 (Factory set)
USB-C
Maximum 20 Hz
Sample Rate
Note: Sampling by pressure or
sound velocity increment is also
available.
Power 2 Cell Internal Battery 21Wh
PC or wall charging over USB
(10W minimum)
8-30VDC via MCBH connector
Note: External power supply should
be able to support at least 10W
output. Please consider voltage
drop when using longer cables.
Temperature
Operation -20 to +45°C
Storage -20 to +60°C
Dimensions
Diameter 10.0 cm / 3.90 in
Length 60.0 cm / 23.6 in
Weight* 4.00 kg / 8.80 lb
Weight in water* 2.00 kg / 4.40 lb
*With no installed sensors, deployment weight will vary.
AML Oceanographic Ltd.
6000m
6000m / 19685 feet
Acetal, 316 stainless steel, titanium,
polycarbonate
30 GB
Sailfish
RS-232 or RS-485 (Factory set)
USB-C
20 Hz
Note: Sampling by pressure or
sound velocity increment is also
available.
2 Cell Internal Battery 21Wh
PC or wall charging over USB (10W
minimum)
8-30VDC via MCBH connector
Note: External power supply should
be able to support at least 10W
output. Please consider voltage drop
when using longer cables.
-20 to +45°C
-20 to +60°C
10.0 cm / 3.90 in
60.0 cm / 23.6 in
5.80 kg / 12.80 lb
3.80 kg / 8.40 lb
8/44
