(solid on)
Green
Battery good
Red
Battery low
Orange/ White/
Blue
White

1.7 Pressure Ratings

Pressure ratings may differ between installed sensors and the instrument body, and
deployments should never exceed the shallower of these ratings. For example, a 500 m
instrument equipped with a 6000 dBar pressure sensor is limited to deployments of 500 m depth
or less. Similarly, a 6000 m instrument equipped with a 500 dBar pressure sensor is also limited
to deployments of 500 m depth or less.
The instrument pressure rating is identified on the end of the instrument, adjacent to the
shackle. Typical ratings for AML-6 RT instruments are 500m and 6000m (note that both ratings
use plastic housings).
AML Oceanographic Ltd.
Steady Single flash
- - - - - -
Ready Logging
Battery good
Ready Logging
Battery low
- -
- -
Smooth transition Rapid flash
-
-
Boot up or boot
down sequence.
- Error state
-
-
-
