Top and Bottom Views
1.0
Mounting slot
Mounting hole
NOTE
Please remove the protective kapton tape covering the encoder ASIC before use.
Figure 1 Bottom Side of the PCB
Figure 2 Top Side of the PCB (Left 318 LPI & Right 225 LPI)
Code wheel OD
alignment guide lines
