Vivo STAND-V001VA Instruction Manual
Vivo STAND-V001VA Instruction Manual

Vivo STAND-V001VA Instruction Manual

Single monitor desk mount with vesa adapter bracket

Advertisement

Quick Links

Single Monitor Desk Mount with
VESA Adapter Bracket
Instruction Manual
SKU: STAND-V001VA
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001va
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V001VA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-V001VA

  • Page 1 Single Monitor Desk Mount with VESA Adapter Bracket Instruction Manual SKU: STAND-V001VA Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001va GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3 TOOLS NEEDED 17.6lbs DO NOT EXCEED WEIGHT CAPACITY. (8kg) Failure to do so may result in serious injury. Phillips Screwdriver ASSEMBLY STEPS STEP 1 Loosen knob on Clamp (B). STEP 2 (Option A) Desk Clamp Installation Mount Clamp (B) to Pole (A) using M6x16mm Screws (S-A) 3mm Allen Wrench (T-A). Secure assembly to desktop by tightening knob on Clamp (B).
  • Page 4 STEP 2 (Option B) Grommet Installation Using a phillips screwdriver, remove the screw from Clamp (B) and disassemble. Set Knob (B2) aside. Mount Grommet Plate (F) to Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Remove adhesive backing from Soft Pad (G) and adhere to Grommet Plate (F). If desk does not have an existing grommet hole, drill a 3/8”...
  • Page 5 STEP 3 Slide Pole Cable Clip (J) and Swivel Arm (C) onto Pole (A). Tighten Swivel Arm (C) at desired height using 6mm Allen Wrench (T-C). Insert Pole Cap (E) into top of Pole (A). Attach arm Cable Clips (I) onto Swivel Arm (C).
  • Page 6 STEP 5 (Continued)
  • Page 7 STEP 6 With all “L” Support Holders (L) facing up, place monitor on lower two holders and fully tighten lower two screws with a Phillips screwdriver. Turn top holders down and tighten top screws, then tighten nuts for the upper arms. Install Plastic Covers (M) into “L” Support Holders (L). STEP 7 Slide monitor assembly onto Swivel Arm (C) and secure with M6 Security Screw (S-E).
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
