Single Monitor Desk Mount with
VESA Adapter Bracket
Instruction Manual
SKU: STAND-V001VA
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001va
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-V001VA
Summary of Contents for Vivo STAND-V001VA
- Page 1 Single Monitor Desk Mount with VESA Adapter Bracket Instruction Manual SKU: STAND-V001VA Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001va GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! PACKAGE CONTENTS If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 STEP 2 - Continued ASSEMBLY STEPS OPTION B: Grommet Installation Use a Phillips screwdriver to loosen screw inside Clamp (B). Disassemble and separate the Hand STEP 1 Crank (B1) and Clamp Plate (B2). Unscrew the hand crank of Clamp (B) to create an opening for the clamp to placed on desktop. STEP 2 Install Grommet Plate (E) to the Pole (A) using M6x16 Screws (S-A) and 3mm Allen Wrench (T-B).
- Page 4 STEP 3 OPTION #1 Slide Pole Cable Clip (L) and Swivel Arm (C) Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), onto Pole (A). Tighten Swivel Arm (C) at desired M4 Nuts (S-C), and Wrench (T-A). height using 5mm Allen Wrench (T-C).
- Page 5 OPTION #2 OPTION #3 Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), M4 Nuts (S-C), and Wrench (T-A). M4 Nuts (S-A), and Wrench (T-A). Place extension bracket assembly over monitor.
- Page 6 STEP 5 CABLE MANAGEMENT Press Plastic Covers (J) over screw holes on “L” Support Holder (I). Route cables through Arm Cable Clip (M) and Pole Cable Clip (L). STEP 6 Slide monitor assembly onto Swivel Arm (C) and secure with M6 Security Screw (S-B). ADJUST AS DESIRED Use 5mm Allen Wrench (T-C) to adjust tilt and swivel on VESA plate head.
- Page 7 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
