Single Monitor Desk Mount
Instruction Manual
SKU: STAND-V001E
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001e
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V001E
Summary of Contents for Vivo STAND-V001E
- Page 1 Single Monitor Desk Mount Instruction Manual SKU: STAND-V001E Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001e GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6lbs Failure to do so may result in serious injury. (7.98kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach plastic cap (C) to top of pole (D). STEP 2 OPTION A: Clamp Installation Stick rubber pads (G) to bottom of clamp (B) as shown in diagram. Align pin in clamp (B) with bottom hole in pole (D).
- Page 4 STEP 2 (Continued) OPTION B: Grommet Installation Remove hand bolt from clamp (B) by first removing phillips screw from top of bolt, then remove plate and unscrew. Stick rubber pads (G) to bottom of grommet base (F). Align pin in grommet base (F) with bottom hole pole (D). Mount pole (D) and grommet base (F) to desktop using grommet plate (I) and previously removed hand bolt.
- Page 5 STEP 4 Insert screws (M-A or M-B) with washers (M-C) into top two holes of monitor, leaving 3mm of thread exposed. Hang monitor over slots in VESA plate. Secure using screws and washers in bottom two holes, and tighten all screws. M-A/M- B M- C 3m m...
- Page 6 STEP 5 If needed, tighten tilt joint using 6mm allen wrench (K). +45 ° -45° STEP 6 Store tools (K, J) in cable management clip (E) for future adjustments.
- Page 7 STEP 7 Manage cables and adjust tilt and rotation of monitor as desired. 360°...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
