Single Monitor Desk Mount
Instruction Manual
SKU: STAND-V001UVM
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001uvm
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V001UVM
Summary of Contents for Vivo STAND-V001UVM
- Page 1 Single Monitor Desk Mount Instruction Manual SKU: STAND-V001UVM Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001uvm GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 - Option A - Desk Clamp Loosen the hand screw on Clamp (B) to open fully, as shown below. Install the Clamp (B) to the Pole (A) using M6x16mm Screws (S-A) and tighten using 3mm Allen Wrench (T-A). - Page 4 STEP 1 - Option B - Grommet Disassemble Clamp (B) into individual parts. Remove Clamp Plate (B1) using Phillips screwdriver and remove Knob (B2). Install Grommet Plate (F) to the Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Attach Soft Pad (G) to the Grommet Plate (F).
- Page 5 STEP 2 Slide Pole Cable Clip (J) and Swivel Arm (C) onto Pole (A). Tighten Swivel Arm (C) at desired height using 5mm Allen Wrench (T-B). Insert Pole Cap (E) into top of Pole (A). STEP 3 Attach Cable Clips (I) onto each segment of Swivel Arm (C).
- Page 6 STEP 4 With the adjustment screw holes on top, mount Adapter (H) to to VESA Plate (D) using M4x16mm Thumbscrews (S-C) with M4 Washers (S-D) and a Phillips screwdriver. Loosly install remaining M4x16mm Thumbscrews (S-C) into the top adjustment holes in Adapter (H). Adjustment Holes To adjust the Adapter (H) to fit the device, push device down onto springloaded tabs and position device against the face of the adapter.
- Page 7 STEP 5 NOTE: Before proceeding, ensure that the tilt joint on Swivel Arm (C) is tight. Use 5mm Allen Wrench (T-B) to secure tilt joint. STEP 6 Slide VESA Plate (D) with adapter and tablet onto the head of Swivel Arm (C). Install the M6 Security Nut (S-B).
- Page 8 STEP 7 Manage cables in Cable Clips (I) and Pole Cable Clip (J). ADJUST AS DESIRED Tighten the screw with the supplied 5mm Allen Wrench (T-B) to fix the tilt angle and to make any necessary adjustments.
- Page 9 OPTIONAL USE: MONITOR MOUNT To use stand as single monitor mount, follow Steps 1-3, then return to these instructions to proceed. STEP 4B Flat Back Monitor Attach the VESA Plate (D) to the monitor with Thumbscrews (M-A) and a Phillips screwdriver. NOTE: Hand tighten screws to avoid over tightening.
- Page 10 STEP 5B Slide VESA Plate (D) with monitor onto the head of Swivel Arm (C). Install the M6 Security Nut (S-B). Make sure the security nut is installed before you rotate the monitor. STEP 6B Manage cables in Cable Clips (I) and Pole Cable Clip (J).
- Page 11 Adjust as Desired Tighten the screw with the supplied 5mm Allen Wrench (T-B) to fix the tilt angle and to make any necessary adjustments.
- Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
