Lateral arm support 10-389
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-15
Document number: M10-389EN rev.01
1
Advertisement
Table of Contents
Related Manuals for Reison 10-389
Summary of Contents for Reison 10-389
- Page 1 Lateral arm support 10-389 Warning! This symbol indicates important information related to safety. Follow these instructions carefully. Read User Manual before use! It is important to fully understand the content of the user manual before attempting to use the equipment.
- Page 2 Intended use Arm support intended for support and positioning of the arm is raised position for patients fixed at side position during surgery. The product is to be used by medical professionals within a medical facility. Safety regulations Maximum load: 15 kg in even distribution, corresponding to a patient weight of 250 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation Position adjustment 360° 360° 40°...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Adjusting the lock mechanism Tool: 2 mm hex key. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts Description Pcs. Article no. Arm plate 11330 Washer 11547 Pivot holder 10300 Pad fixture 11550 Washer 10004 Screw MF6S M6x12 A2 Strap 10-383-L 11551 Plastic plug IKP 2015-17-S Post 11798 Nut left threaded 10302 Adjustment nut 10301 Set screw MSK6SS M5x8 A2 Screw 10303 Set screw MSK6SS M4x5 A2...
- Page 6 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
