Specifications
For specifications on the available copper Ethernet ports, refer to "Copper Ethernet
Port Specifications" (Page 30).
4.2
SFP Transceivers
The RUGGEDCOM RST916C supports up to four Small Form-Factor Pluggable (SFP)
transceiver sockets, which are compatible with a wide array of SFP transceivers
available from Siemens.
LEDs
Each socket features an LED that indicates its link state.
Green (Solid)
Green (Blinking)
Off
Compatible SFP Transceivers
For more information about which SFP transceivers are compatible with the
RUGGEDCOM RST916C, as well as instructions for ordering and installation/
removal, refer to the
support.industry.siemens.com/cs/ca/en/view/109482309]".
Note
Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens
accepts no liability as a result of performance issues related in whole or in part to
third-party components.
RUGGEDCOM RST916C
Installation Manual, 04/2023, C79000-G8976-1490-07
Pin
10/100Base-TX
8
Reserved (Do Not Connect)
State
"RUGGEDCOM SFP Transceiver Catalog [https://
Name
1000Base-TX
BI_DC-
Link established
Activity
No link detected
Communication Ports
4.2 SFP Transceivers
Description
Bi-Directional
Description
27
