Removing the CLP
To remove the CLP, do the following:
Configuration hazard – risk of data loss
After uploading or downloading a file, allow at least twenty seconds before
removing the CLP to ensure the data has been fully transferred.
1.
2.
Inserting the CLP
To insert the CLP, do the following:
1.
RUGGEDCOM RST916C
Installation Manual, 04/2023, C79000-G8976-1490-07
NOTICE
Remove the CLP (or blank insert) from the CLP port. If needed, insert a flat head
screwdriver between the CLP and the chassis to gently pry the CLP out.
2
1
Blank Insert
1
CLP
2
Figure 3.1 Removing the CLP
NOTICE
Contamination hazard – risk of dust and dirt entering the CLP slot
When the CLP is not installed, make sure a blank insert (provided with each
device) is installed in its place.
Insert a blank insert or a new CLP.
Remove the current CLP (or blank insert) from the device.
Device Management
3.3 Inserting/Removing the CLP
