Figure 2.14
LO Power Supply Configurations
Figure 2.16
RUGGEDCOM RST916C
Installation Manual, 04/2023, C79000-G8976-1490-07
Dual HI AC and DC Power
Supplies
Single LO DC Power Input
Configuration
2.5.2 Wiring Examples
Figure 2.15
Dual HI DC Power Supplies
Figure 2.17
Dual LO DC Power Input
Configuration
Installing the Device
19
