Application Guidelines
No. Parts Name Parts No
34 COIL,SOLENOID SSA382F230
35 COIL,SOLENOID SSA382F230A
36 WIRING ASSY PCM504A018AV
37 VALVE ASSY,S(OIL) LCA382A018
38 VALVE ASSY,S(HG) LCA382A002
Control
39 PWB ASSY(CONTROL) PCM505A011BD
40 PWB ASSY(INV.) PCB505A107CB
41 PWB ASSY(N.F) PCB505A035H
42 PWB ASSY(POWER) PCB505A114A
43 PWB ASSY LCA505A003D
44 PWB ASSY(REMOTE) PCM505A009A
45 TRANSFORMER ASSY PCB554A021
46 TRANSISTOR(POWER) PCB008A177B
47 DIODE(MODULE) PCB008A121A
48 RESISTOR SSA553A536
49 CAPACITOR SSA552F694
50 CAPACITOR SSA552F427AK
51 RESISTOR SSA553A380
52 MOTOR ASSY,AC PCB511A006F
53 SENSOR ASSY LCA551A002
54 SENSOR ASSY LCA551A002A
55 SENSOR ASSY LCA551A005
56 SENSOR ASSY LCA551A003
57 WIRING ASSY PCM504A018AP
58 WIRING ASSY PCM504A006J
59 WIRING ASSY PCM504A006L
60 WIRING ASSY PCM504A006M
61 WIRING ASSY PCM504A006N
62 WIRING ASSY PCM504A018K
63 WIRING ASSY PCM504A018L
64 WIRING ASSY PCM504A018AC
65 WIRING ASSY LCA504A004
66 WIRING ASSY PCM504A006Z
67 WIRING ASSY PCA504A273
68 WIRING ASSY PCM504A018AJ
69 HARNESS ASSY LCA504A001
70 WIRING ASSY PCM504A023
71 DRYER SSA356A004
72 OIL (MA68 4LX6) LCA006A005
73 OIL (MA68 0.5LX20) LCA006A007
74 OIL (MA68 0.5LX1) LCA006A008
CO2 MODULE CONTROLLER UNIVERSAL GATEWAY
75 MODULE CONTROLLER 118U5498
© Danfoss | Climate Solutions | 2023.02
2. Product description
Danfoss Requirements
Gross
Unit Dimension (mm)
weight
Kg Length Width
0.152 105 85
0.157 105 85
0.300 225 300
1.400 400 340
0.474 370 220
0.900 370 285
0.468 220 200
1.100 250 180
0.989 305 175
0.145 170 150
0.130 195 125
0.030 300 175
0.429 160 95
0.231 125 80
0.124 105 85
0.125 105 85
0.811 165 90
0.049 150 80
0.725 160 160
0.052 300 175
0.058 300 175
0.073 300 175
0.115 300 225
0.038 300 175
0.025 175 150
0.084 105 85
0.007 150 125
0.034 175 150
0.055 105 85
0.053 105 85
0.020 175 150
0.002 150 85
0.039 300 175
0.016 250 175
0.018 175 150
0.038 105 85
0.022 300 175
1.500 200 110
27.00 420 410
23.00 470 380
1.500 90 90
2.600 182 90
Packing
Remarks
Style
Height
55 Carton box Coil for EEVLB, CPM-MD12SM-1, Rated voltage:DC12V
55 Carton box Coil for EEVSC, CPM-MD12SM-2, Rated voltage:DC12V
40 Vinyl bag Wiring for compressor
Valve ASSY of SV-OIL1-2, Connection size:inlet Φ6.35 outlet
270 Carton box
Φ6.35
Valve ASSY of SVHG1, Connection size:inlet Φ6.35 outlet
100 Carton box
Φ9.52
85 Carton box Only for supply parts PWB1
80 Carton box Only for supply parts PWB2
70 Carton box PWB3
100 Carton box Only for supply parts PWB5
70 Carton box Only for supply parts PWB6
60 Carton box PWB7
10 Vinyl bag Current transformer, GJ-4-X, 4.1V±3%/50A(50/60Hz, 150Ω)
65 Carton box Only for supply parts TM, PM50CL1A120
55 Carton box Only for supply parts DM, PGH75N16
55 Carton box R1-1,2,3, 26500-0600, 7.5Ω
55 Carton box Capacitor, PC78D125-225K, Capacitance 2.2μF
85 Carton box Capacitor, LNX2G472MSEBMZ, Capacitance 4700μF
15 Vinyl bag R3, 32500-1070, 30kΩ
Fan motor, UP12D23-GTEW, Rated output 16W, Rated
80 Carton box
voltage:230V 1 phase 50/60Hz
10 Vinyl bag THO-G1,G2
10 Vinyl bag THO-M1,INJ1
10 Vinyl bag THO-D1,S,C1
10 Vinyl bag THO-SC,R,A
15 Vinyl bag PWB3-1 L1 ,PWB3-1 N ,PWB3-1 L2 - PWB1 CNW1,PWB1 CNW2
15 Vinyl bag 52X1-1 5,52X1-2 5,52X1-2 6,52X1-1 6- PWB1 CNM1
55 Carton box PWB5 CN13-2- PWB1 CNDR,PWB1 CN13V
10 Vinyl bag PWB1 CN15V- PWB5 CN15V-2
30 Vinyl bag PWB1 CN18V- PWB5 CN18V-2
55 Carton box PWB5 CNA1-2- FM1 CNDC1
55 Carton box PWB5 CNA2-2- FM2 CNDC2
15 Vinyl bag PWB1 CNN3- FMC1,FMC2
10 Vinyl bag PWB1 CNS1
10 Vinyl bag PWB1 CNI1- PWB2-1 CNI2
10 Vinyl bag DM1 G,DM1 K- PWB2-1 CNR
15 Vinyl bag C2 -,C1 +- PWB2-1 CAN
55 Carton box OLS1- CNTH7,CNZ
10 Vinyl bag CN1- CNV1
Filter dryer, DCY-P8 165 S/MMS, Connection size:inlet Φ16.1
110 Carton box
outlet Φ16.1
290 Carton box Oil, 6PCS/1pack carton
290 Carton box Oil, 20PCS/1pack carton
260 Carton box Oil, 1PCS/1pack carton
180 Carton box
