Assembly Instructions & User's Manual
For
Member's Mark
Halstead Towel Valet
Item Number: 990018888
Model Number: GT-12289A-AAR
Customer Assistance
: 1-888-691-2824
(spare/replacement parts)
or Email:
customerservice@coronadocasuals.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark GT-12289A-AAR
Summary of Contents for Member's Mark GT-12289A-AAR
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Halstead Towel Valet Item Number: 990018888 Model Number: GT-12289A-AAR Customer Assistance : 1-888-691-2824 (spare/replacement parts) or Email: customerservice@coronadocasuals.com THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................3 Important Safety Information ........................3 Before Assembly .............................3 Care & Use ..............................3 Package Contents ...........................4 Product Information ..........................5 Components ..............................5 Hardware ..............................5 Tools ................................5 Step 1 .................................6 Step 2 ............................7 Step 3 .................................8 Step 4 ............................9 Step 5 ............................10 Warranty Information ..........................11 P a g e... -
Page 3: Quality Statement
Quality Statement Important Safety Information Please read all instructions carefully before assembling this product. Where applicable, and for your safety, assembly by an adult is strongly recommended. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Left leg frame Woven panel 2 Right leg frame Woven panel 3 Allen/Hex Head Bolt Shelf 1 M6x40mm Shelf 2 Allen/Hex Head Bolt M6x35mm Shelf 3 Allen/Hex Head Bolt M6x20mm Woven panel 1 M6 Washer Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 5: Product Information
Product Information Product Dimensions Towel Valet: 31.75"x20"x60.4" (80.6cmx 50.8cmx 153.4cm) Product Weight Capacity Table: Supports up to 100 lbs. (45 kg) Components Left leg frame Right leg frame Shelf 1 Shelf 2 Qty: 1pc Qty: 1pc Qty: 1pc Qty: 1pc Woven panel 1 Shelf 3 Woven panel 2... -
Page 6: Step 1
Step 1 Left leg frame Shelf 1 Shelf 2 Shelf 3 Qty: 1pc Qty: 1pc Qty: 1pc Qty: 2pcs Allen/Hex Head Bolt Allen/Hex Head Bolt M6 Washer M6 Allen Wrench Qty: 10pcs M6x35mm M6x20mm Qty: 1pc Qty: 8pcs Qty: 2pcs Carefully place the Left leg frame (A) upside down on a non-abrasive surface. -
Page 7: Step 2
Step 2 Right leg frame Allen/Hex Head Bolt Allen/Hex Head Bolt M6 Allen Wrench M6 Washer Qty: 1pc Qty: 10pcs M6x35mm M6x20mm Qty: 1pc Qty: 8pcs Qty: 2pcs Assemble the Shelf 1 (C), Shelf 2 (D) and Shelf 3 (E) to Right leg frame (B) with M6 bolts (K), M6 bolts (J) and M6 Washer (L) by using M6 Allen Wrench (M). -
Page 8: Step 3
Step 3 Woven panel 1 Allen/Hex Head Bolt M6 Allen Wrench Woven panel 3 M6 Washer Qty: 2pcs Qty: 4pcs Qty: 1pc M6x40mm Qty: 1pc Qty: 4pcs Assemble the Woven panel 1 (F) to Woven panel 3 (H) with M6 bolts (I) and M6 Washer (L) by using M6 Allen Wrench (M). -
Page 9: Step 4
Step 4 Allen/Hex Head Bolt M6 Allen Wrench Woven panel 2 M6 Washer Qty: 8pcs Qty: 2pcs M6x40mm Qty: 1pc Qty: 8pcs Assemble the Woven panel 2 (G) to Woven panel 3 (H) with M6 bolts (I) and M6 Washer (L) by using M6 Allen Wrench (M). Tighten all bolts with M6 Allen Wrench (M). -
Page 10: Step 5
Step 5 Carefully turn the Towel Valet over. The Towel Valet is ready for your enjoyment. Need Assistance? Visit us at: samsclub.com/membersmarkhelp 10 | P a g e... -
Page 11: Warranty Information
Warranty Information This product component has a 5 year guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number customerservice@coronadocasuals.com 1-888-691-2824 or email us at NOTE: Please consider recycling all applicable packaging material.
