Assembly Instructions & User's Manual
for
Member's Mark Bisbee Rope Swing
Item Number: 990017829/990017830
Model Number: GCS09137A
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark GCS09137A
Summary of Contents for Member's Mark GCS09137A
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Bisbee Rope Swing Item Number: 990017829/990017830 Model Number: GCS09137A Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
- Page 2 Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................5 Tools ................................5 Step 1 – Step 5 ............................6 Troubleshooting ............................
- Page 3 Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 4 Package Contents Component Description Quantity Component Description Quantity Base Seat cushion Pole Stand Back cushion Chair Frame with Bungee attached Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 5 Product Information Dimensions: Swing chair: dia.41.3”x77.1”(dia.105cm x 196cm) Weight Capacity: Swing Chair: Supports up to 250 lbs. (113.4kg.) Components Base Pole Stand Chair Frame with Bungee Qty 1 Qty 1 attached Qty 1 Seat cushion Back cushion Qty 1 Qty 1 Hardware M8X60 Bolt M8 Washer...
- Page 6 Step 1 – Step 5 Step 1 Step 2 Slide the Pole Stand (B) into the Base (A). Align holes and Open the locking carabiners by turning the locking bolt. insert M8x60 Bolt (AA), Washer (BB) into the See step 1.Hang the Spring (EE) to the pole stand (B) corresponding holes and tighten Nut (CC) and Bolt (AA) using the carabiner, while attaching the opposited end with Wrench and Allen Wrench.
- Page 7 Troubleshooting Problem Possible Cause Prevention / Solution Chair Frame with Spring with Carabiners may loosen Periodically check that Spring with overtime. Bungee attached Carabiners are tight. drop Chair Frame swing Bungee with Carabiners may Periodically check that Bungee with outside base area loosen overtime.
- Page 8 Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
