The µVision3 IDE integrates all the tools necessary to edit, assemble and debug code. The ADuC706x Development System supports non-intrusive
emulation limited to 16kByte code.
2.1 Starting µVision3
1. From the START menu choose Programs
C:\Keil\UV3\Uv3.exe. µVision3 can use the GNU tools which should have been installed in the C:\Cygnus\ directory.
2.2 Toolbars
2. Under the VIEW menu, four toolbars are available:
a. Status Bar
b. File Toolbar
c. Build Toolbar
d. Debug Toolbar
The Build Toolbar will be active only when the IDE is in Edit/Compile mode. The Debug toolbar will be active only in Download/Debug
mode.
2.3 Starting a project
3. From the project menu select New Project as shown below.
4. Create a new folder ADIdemo under C:\Keil\ARM\ Examples and enter the name of the project as Demo. You will then be asked to select the
device. Select the part number corresponding to your evaluation board under Analog Devices. For simplicity, this GetStarted guide will always
refer to the ADuC7060.
The following message appears. Select "No" not to include
automatically the startup file startup.s to your project.
REV 1.0
http://www.elecfans.com 电子发烧友 http://bbs.elecfans.com 电子技术论坛
µ µ µ µ V 3 I
ISION NTEGRATED
Keil uVision3. This loads the µVision3 IDE. The µVision3 executable is located at
ADuC706x GetStarted Guide
(2) Keil µVision3 Integrated Development Environment
