14. To start debugging, select Start/Stop Debug in the Debug
dropdown menu or press the icon
session). The debugger will indicate that you are using an
evaluation version. Press OK.
15. From the Peripheral pull down menu, select Digital/Analog Converter, DAC1 and select Analog/Digital Converter.
The following window will appear:
Close the disassembly window. Go to Timer1_IRQ.c file. Set a breakpoint on the instruction while (1) This is done by right clicking on the line
16.
of code and then selecting "insert/remove breakpoint" or by double clicking on the left of the instruction. Notice that the breakpoint is
indicated by a large red dot to the left of the line.
REV 1.0
http://www.elecfans.com 电子发烧友 http://bbs.elecfans.com 电子技术论坛
(Start/stop debug
(2) Keil µVision3 Integrated Development Environment
-- 12 --
ADuC706x GetStarted Guide
