Symmons Allura S-4701-TRM Operation & Maintenance Manual

S-4700-TRM, S-4701-TRM, S-4702-TRM
Allura Trim Series
®
Operation & Maintenance Manual
Model Numbers
S-4700-TRM
Valve Trim
S-4701-TRM
Shower Trim
S-4702-TRM
Tub/Shower Trim
Options/Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-LAM
Metal finish insert handle
-LR
Lever handle
-SS
Slip spout on any tub and shower unit
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Specification
Tub/shower trim with lever handle and secondary
diverter lever handle includes non-diverter tub spout
and 3 mode showerhead with standard 2.5 gpm
(9.5 L/min) flow restrictor. Shower trim with lever handle
and secondary volume control lever handle includes
all of the above less non-diverter tub spout. Valve trim
with lever handle and secondary lever handle includes
valve trim only. Components made from metal and
nonmetallic materials plated in standard polished
chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
For California Residents
WARNING: This product contains chemicals known to
the State of California to cause cancer, birth defects, or
other reproductive harm.
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
