Led3:
Green
Not used
Port RS232 (D-SUB9-Male)
PIN2 = TX
PIN3 = RX
PIN5 = GND
Used for:
A) Programmation Port
B) Modbus on RS232
To connect the device to the COM
port of a PC in order to set it.
You have to use the programming
AC34107.
cable
Or a cable made as showed here:
CABLE CABLE
Side A Side B
FEM FEM
Figure 2: Connection scheme for HD67012
ADFweb.com Srl – IT31010 – Mareno – Treviso
Jumper1:
Termination CANopen Line
Connector1:
Power Supply
= Open
V- = Ground
V+ = Positive wire
12/18 VAC – 4 VA
12/24 VDC – 4 Watt
Rail DIN
Clamp
Led1:
Yellow Led2:
Boot Mode: Blink Green
quickly; RUN
No Boot Mode:
Change when CAN
message arrive
User Manual CANbus / Modbus Slave
Document code: MN67012_ENG
Connector2:
CAN
H = High wire
S = Shield
L = Low wire
= 120 ohm
V – V+ H S L S B A
12 Vac
Or
24 dc
-- + Hi Grd Lo S -- +
INFO: www.adfweb.com
Revision 2.101 Page 5 of 17
Jumper2:
Termination Modbus Line
= Open = 220 ohm
Connector3:
Modbus RTU on RS485
S = Shield
B = Negative wire
A = Positive wire
Jumper3:
Boot mode
= Yes Jumper
Boot Mode
= No Jumper
Normal Mode
