One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluation Board for the ADM8611/ADM8612/ADM8613/ADM8614/ADM8615, Ultra
Low Power Supervisory ICs with Watchdog Timer and Manual Reset

FEATURES

Pretrimmed voltage monitoring threshold
2.63 V for ADM8611-EVALZ with ±1.3% accuracy
1.10 V for ADM8612-EVALZ with ±1.4% accuracy
2.32 V for ADM8613-EVALZ with ±1.3% accuracy
2.63 V for ADM8614-EVALZ with ±1.3% accuracy
1.00 V for ADM8615-EVALZ with ±1.6% accuracy
Manual reset (MR#) pin for input condition override (all boards
except ADM8614-EVALZ)
Separate voltage supply (VCC) and input pin (INPUT) for low
voltage monitoring (ADM8612-EVALZ/ADM8615-EVALZ)
Watchdog timer input (WDI) pin for monitoring an external
microprocessor (ADM8613-EVALZ/ADM8614-EVALZ/
ADM8615-EVALZ)
Watchdog disable input (WD_DIS) pin (ADM8613-EVALZ/
ADM8614-EVALZ)
Watchdog timeout selection input (WDT_SEL) pin for
extending the timer period (ADM8614-EVALZ)
Built in tact switch (JP1) for input condition override (all
boards except ADM8614-EVALZ)
Built in LED for output monitoring
Table 1. ADM8611-EVALZ/ADM8612-EVALZ/ADM8613-EVALZ/ADM8614-EVALZ/ADM8615-EVALZ Series Selection Table
Low Voltage
Device Number
Programming
ADM8611-EVALZ
No
ADM8612-EVALZ
Yes
ADM8613-EVALZ
No
ADM8614-EVALZ
No
ADM8615-EVALZ
Yes
1
See the Evaluation Board Photographs section for full size photographs.
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
ADM8611-EVALZ
Manual
Watchdog
Reset
Timer Input
(MR#)
(WDI)
Yes
No
Yes
No
Yes
Yes
No
Yes
Yes
Yes
Rev. 0 | Page 1 of 18
to
ADM8615-EVALZ

GENERAL DESCRIPTION

The ADM8611-EVALZ/ADM8612-EVALZ/ADM8613-EVALZ/
ADM8614-EVALZ/ADM8615-EVALZ boards demonstrate the
ADM8611/ADM8612/ADM8613/ADM8614/ADM8615
features summarized in Table 1. These ultra low power voltage
supervisors monitor the input voltage level and compare it against
an internal reference.
This user guide describes how to set up and use the boards to
demonstrate the product functions. Full details about the
ADM8611/ADM8612/ADM8613/ADM8614/ADM8615
available in the product data sheet, which must be consulted in
conjunction with this user guide when using the ADM8611-EVALZ/
ADM8612-EVALZ/ADM8613-EVALZ/ADM8614-EVALZ/
ADM8615-EVALZ.
Watchdog
Watchdog Timeout
Disable Input
Selection Input
(WD_DIS)
(WDT_SEL)
No
No
No
No
Yes
No
Yes
Yes
No
No
User Guide
UG-1767
with the
are
Evaluation Board
Photograph
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADM8611 and is the answer not in the manual?

Questions and answers

Related Manuals for Analog Devices ADM8611

Summary of Contents for Analog Devices ADM8611

  • Page 1: Features

    Separate voltage supply (VCC) and input pin (INPUT) for low ADM8611/ADM8612/ADM8613/ADM8614/ADM8615 voltage monitoring (ADM8612-EVALZ/ADM8615-EVALZ) available in the product data sheet, which must be consulted in Watchdog timer input (WDI) pin for monitoring an external conjunction with this user guide when using the ADM8611-EVALZ/ microprocessor (ADM8613-EVALZ/ADM8614-EVALZ/ ADM8612-EVALZ/ADM8613-EVALZ/ADM8614-EVALZ/ ADM8615-EVALZ) ADM8615-EVALZ.

  • Page 2: Table Of Contents

    Evaluation Board Connection Diagrams ........5   PCB Layout ................. 14   Using the Evaluation board ............. 8   Bill of Materials ................16   ADM8611-EVALZ ............... 8 REVISION HISTORY 7/2020—Revision 0: Initial Version Rev. 0 | Page 2 of 18...

  • Page 3: Evaluation Board Photographs

    ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 EVALUATION BOARD PHOTOGRAPHS Figure 1. ADM8611-EVALZ Figure 4. ADM8614-EVALZ Figure 2. ADM8612-EVALZ Figure 5. ADM8615-EVALZ Figure 3. ADM8613-EVALZ Rev. 0 | Page 3 of 18...

  • Page 4: Adm8611-Evalz/Adm8612-Evalz/Adm8613-Evalz/Adm8614-Evalz/Adm8615-Evalz Series

    . The internal timer is cleared every time a logic of the status of the monitored input voltage by pressing the built transition of as short as 85 ns is detected on the ADM8613- in tact switch, JP1, which shorts the ADM8611-EVALZ/ EVALZ/ADM8614-EVALZ/ADM8615-EVALZ WDI pin. The ADM8612-EVALZ/ADM8613-EVALZ/ADM8615-EVALZ MR# watchdog timer can be disabled by driving the ADM8613-EVALZ/ pin to ground.

  • Page 5: Evaluation Board Connection Diagrams

    ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 EVALUATION BOARD CONNECTION DIAGRAMS POWER SUPPLY OSCILLOSCOPE + – + – Figure 6. ADM8611-EVALZ Connection Diagram POWER SUPPLY OSCILLOSCOPE + – + – Figure 7. ADM8612-EVALZ Connection Diagram Rev. 0 | Page 5 of 18...
  • Page 6 UG-1767 ADM8611-EVALZ ADM8615-EVALZ User Guide OSCILLOSCOPE POWER SUPPLY + – + – Figure 8. ADM8613-EVALZ Connection Diagram POWER SUPPLY OSCILLOSCOPE + – + – Figure 9. ADM8614-EVALZ Connection Diagram Rev. 0 | Page 6 of 18...
  • Page 7 ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 POWER SUPPLY OSCILLOSCOPE + – + – Figure 10. ADM8615-EVALZ Connection Diagram Rev. 0 | Page 7 of 18...

  • Page 8: Using The Evaluation Board

    This section explains how to evaluate the performance of the This section explains how to evaluate the performance of the ADM8611. Refer to Figure 1, Figure 6, Figure 11, Figure 16, and ADM8612. Refer to Figure 2, Figure 7, Figure 12, Figure 17, and...

  • Page 9: Adm8613-Evalz

    ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 ADM8613-EVALZ Vary the supply voltage of the ADM8613-EVALZ VCC pin slowly from 2 V to 2.5 V while monitoring This section explains how to evaluate the performance of the the ADM8613-EVALZ RESET# pin waveform until the ADM8613.

  • Page 10: Adm8615-Evalz

    UG-1767 ADM8611-EVALZ ADM8615-EVALZ User Guide Keep the external jumper on the ADM8613-EVALZ ADM8615-EVALZ WD_DIS pin to VCC. This section explains how to evaluate the performance of the Take the following steps to check the input: ADM8615. Refer to Figure 5, Figure 10, Figure 15, Figure 23,...
  • Page 11 ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 The value of V and V on the select a divider combination for R3 and R4 in the schematic CC_RESET_THRESH_FALL CC_RESET_THRESH_RISE ADM8615-EVALZ is about 2 V (1.968 V to 2.032 V) and the shown in Figure 15.

  • Page 12: Evaluation Board Schematics And Artwork

    UG-1767 ADM8611-EVALZ ADM8615-EVALZ User Guide EVALUATION BOARD SCHEMATICS AND ARTWORK SCHEMATICS 10kΩ ADM8611 RESET 0.1µF BUTTON 20kΩ Figure 11. ADM8611-EVALZ Schematic Figure 12. ADM8612-EVALZ Schematic 20kΩ ADM8613 RESET WD_DIS 0.1µF RESET WD_DIS BUTTON 100kΩ Figure 13. ADM8613-EVALZ Schematic Rev. 0 | Page 12 of 18...
  • Page 13 ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 10kΩ ADM8614 RESET WD_DIS 0.1µF WDT_SEL RESET WD_DIS 20kΩ WDT_SEL Figure 14. ADM8614-EVALZ Schematic 10kΩ ADM8615 0.1µF VCC_SEL BUTTON 20kΩ INPUT 100kΩ 100kΩ Figure 15. ADM8615-EVALZ Schematic Rev. 0 | Page 13 of 18...

  • Page 14: Pcb Layout

    UG-1767 ADM8611-EVALZ ADM8615-EVALZ User Guide PCB LAYOUT Figure 16. ADM8611-EVALZ Top Assembly Figure 19. ADM8611-EVALZ Bottom Assembly Figure 20. ADM8612-EVALZ Bottom Assembly Figure 17. ADM8612-EVALZ Top Assembly Figure 21. ADM8613-EVALZ Bottom Assembly Figure 18. ADM8613-EVALZ Top Assembly Rev. 0 | Page 14 of 18...
  • Page 15 ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 Figure 24. ADM8614-EVALZ Bottom Assembly Figure 22. ADM8614-EVALZ Top Assembly Figure 25. ADM8615-EVALZ Top Bottom Assembly Figure 23. ADM8615-EVALZ Top Assembly Rev. 0 | Page 15 of 18...

  • Page 16: Bill Of Materials

    C&K 10 kΩ, 1% resistor, R0603 CRCW060310K0FKEA Vishay Dale 20 kΩ, 1% resistor, R0603 CRCW060320K0FKEA Vishay Dale GND pin/test point 61304011121 Würth Elektronik ADM8611, 6-ball WLCSP ADM8611N263ACBZ-R7 Analog Devices Table 3. ADM8612 Bill of Materials Reference Description Part Number Vendor 0.1 μF capacitor, C0603...
  • Page 17 ADM8611-EVALZ ADM8615-EVALZ User Guide UG-1767 Table 5. ADM8614 Bill of Materials. Reference Description Part Number Vendor 0.1 μF capacitors, C0603 GRM188R71H104KA93 Murata LED, R0805 SML-LXT0805IW-TR Lumex TP1, J1 GND pin/test point 61304011121 Würth Elektronik VCC pin/test point 61304011121 Würth Elektronik...
  • Page 18 By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you have read and agreed to the Agreement.
