Specifications

11 Specifications
• Enclosure
Dimensions
Weight .................................................................................................................... 250 g
Protection ................................................................................................................. IP20
• Mounting
Spring-action plastic mounting clips (x 2)
Connections
•
Soft starter ........................................................................................ 6-way pin assembly
Network ................................. 5-way male and unpluggable female connector (supplied)
Maximum cable size ........................................................................................... 2.5 mm
Contacts .......................................................................................................... Gold flash
Settings
•
Node address (MAC ID)
Setting ............................................................................................... Rotary switches
Range ............................................................................... 0 ~ 63 (63, factory default)
Data rate
Setting ............................................................................................... Rotary switches
Options ........................................... 125 kB, 250 kB, 500 kB (125 kB, factory default)
• Power
Consumption
steady state .................................................................................... 19 mA @ 25 VDC
........................................................................................................ 31 mA @ 11 VDC
inrush (at 24 VDC) ............................................................... 1.8 A maximum for 2 ms
Galvanically isolated
Certification
•
CE ............................................................................................................. EN 60947-4-2
RoHS ................................................................ Compliant with EU Directive 2011/65/EU
ODVA .......................................................................................................
8
........................................................ 40 mm (W) x 166 mm (H) x 90 mm (D)
DeviceNet Module
2
CONFORM AN CE TESTED
