- Page 1 INSTALLATION GUIDE HVS-6000ME HVS-6000MV HVS-6000SDI-EX HVS-6000SDO HVS-6000IP-8IO Edition...
-
Page 2: Upon Receipt
Upon Receipt HVS-6000 optional cards are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately. - Page 3 M/E 3 slot and DSK expansion is provided when installed in the OPTION slot. ◆ HVS-6000MV HVS-6000MV is a Multiview video output expansion card for HVS-6000. One card can be installed as an option. By installing the HVS-6000MV, four channels (MV1-MV4) of multi-view video output can be added, allowing you to monitor input video and composited output video.
- Page 4 Lower Slots Slot Slot label Installable cards OUTPUT 2 (Standard) AUXOUT 9-16 HVS-6000SDO M/E 2 (Standard) M/E 2 HVS-6000ME HVS-6000SDI-EX, HVS-6000SDO or AUXOUT 25-32 I/O 2 (Option) EXT INPUT 73-80 HVS-6000IP-8IO OPTION (Option) OPTION HVS-6000ME or HVS-6000MV...
- Page 5 For the slot position, see Sec. 1. "Card Installation Slot". The following procedure shows how to install an HVS-6000SDO into the I/O 1 slot. (1) Turn OFF the power switches on the front of the HVS-6000. HVS-6000 DIGITAL VIDEO SWITCHER (2) Verify that the POWER indicator is lit orange, and then disconnect the power cord from the rear panel.
- Page 6 (14) Re-install the front panel. (15) Re-plug the power cords on the back of the HVS-6000 and turn on the power switches on the front. (16) Open the [SETUP > STATUS > VERSION > MU IN/OUT] menu in the OU and check card versions.
-
Page 7: Version Check
2-1. Version Check ◆ HVS-6000SDI-EX / HVS-6000SDO / HVS-6000IP-8IO Open the [SETUP > STATUS > VERSION > MU IN/OUT] menu in the OU and refer to the table below to check whether the card version is displayed (the card is properly recognized) under card installed slots. - Page 8 FOR-A COMPANY LIMITED 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan Tel: +81(0)3-3446-3936 Fax: +81(0)3-3445-5116 https://www.for-a.com/...
