5
INSTALLATION
Cale strongly recommend the following conditions and settings to be taken into
account when planning and installing solar operated CWT Compact terminals.
Deviations from the guidelines will result in lower efficiency from the solar panel
which may lead to operational issues depending on location, configuration,
maintenance and usage frequency.
Site preparations
•
Installing the terminal
•
Program loading
•
Changing the terminal's settings
•
5.1
Site preparations
Before installing a terminal you must verify that its location meets the
requirements listed in the following section to secure proper operation.
Minimal site dimentions & Mounting holes
•
Solar power positioning
•
Placing the terminal on an existing concrete foundation
•
Pouring a new concrete foundation
•
Power supply
•
5.1.1
Minimal site dimensions & Mounting holes
The given distances between fixed objects at the back and the sides of the
terminal are minimum recommended distances:
The distance behind the terminal enables easy handling while mounting the
•
terminal and also some vertical adjustment of the terminal. This distance is
strongly dependent on GSM/GPRS reception and should be increased in
poor situation.
The distance at the left side ensures that the doors can be fully opened.
•
The distance at the right side allows easy insertion of the door key and also
•
gives enough space if a locking mechanism needs to be repaired.
Issue 13
CWT Compact Touch Installation and Maintenanace Manual
Page 55
