Remove the scanner by unscrewing the four marked screws
•
If needed remove the window.
•
Note:
The windows is fixed in the door with Very Heavy Tape and will be hard to
remove. Press the window from the outside inwards
Clean the surface
•
Add the new tape to the new window and place it in the door.
•
Mount the new scanner in reverse order
•
The cable is on the main board connected to connector J35
•
8.9 Cabinet & pedestal

Cabinet and pedestal lacquer, touching up

8.9.1
Cale Access AB provides kits including touch-up paint (3 x 0.3 litres), sandpaper
and instructions. When ordering, please state the article number and the colour
number (usually a RAL number) indicated on labels inside the cabinet and
pedestal.
