Mechanical Design; General; Product Label - FLOWBIRD CWT Compact Touch Manual

4.8

Mechanical design

In this Chapter:

General

•

Product label

•
Inside the cabinet
•
Inside the pedestal
•
Door locks
•
Door-open sensors
•
4.8.1 General
The terminal comes in 2 parts:
1. the upper part or Cabinet. See
2. the lower part or Pedestal. See
The cabinet can be detached from the pedestal and this is the way the CWT
Compact is usually delivered from the factory.
The cabinet can be removed from the pedestal at a later stage, for example for
maintenance or upgrading reasons, or if the terminal is to be taken out of
operation for a lengthy period.
The configuration of the CWT Compact is highly flexible and varies depending on
installed pay units etc.
4.8.2 Product label
Both the cabinet and the pedestal have a product label specifying the Type,
Colour, and Quality Inspection during production
The figure below depicts the information shown on the product label attached
inside the cabinet.
Issue 13 CWT Compact Touch Installation and Maintenanace Manual
Inside the cabinet
Inside the pedestal
