Included in this package

Mounting bracket
Rear Outlet Mesh Cover (SPLC models only)
Contents check list, checked and signed by Selectronic
Know Your SP PRO display quick reference card
Warranty card.
Tool kit - (Hex Drive bits - T10 Torx, T20 Torx, T25 Torx, 5 mm Hex, 6 mm Hex, long extension)
SP LINK software, this manual and helpful information packaged on USB Memory device
USB Cable - Type B

Benefits of SP LINK

Provided with your SP PRO inverter is a free copy of the SP LINK software. Without SP LINK the SP PRO
will operate with the default settings which are the SP PRO in Off Grid mode using Sealed battery voltage
parameters and Automatic Generator Control based on battery voltage.
Using SP LINK software on your PC allows you to access the different operating modes of the SP PRO and
adjust the configuration parameters within the SP PRO to allow you to integrate the SP PRO into your energy
system.
SP LINK accesses a host of monitoring features allowing you to keep an eye on exactly what your system is
doing and how it is performing.
Your PC can be connected to your SP PRO via USB, RS232 serial port or Wireless (with optional adaptor) to
open the window to the full feature potential of your SP PRO Energy System

Glossary of Terms

DC Coupled system Where the Solar is connected to the DC side of the inverter system through a Solar
Controller.
AC Coupled system Where the Solar is connected to AC Side of the inverter system via a separate Grid Tie
inverter.
Solar Hybrid
A battery based system that is connected to the electricity grid
AC Source
The primary AC input that is connected to the SP PRO, e.g., Grid, Auto start Generator,
Shore Power.
Site File
An SP LINK file that is set up for each SP PRO inverter to be connect to.
Configuration File
Contains all the settings to be loaded into the SP PRO. This is normally linked to a site
file
Solar Array
A collection of Solar Panels.
PV
Photo voltaic solar power
State of Charge
(SoC) Referring to the battery charge condition. 100% SoC means a full battery.
Sealed Battery
A lead acid battery with no access to the electrolyte - either valve regulated or gel. No
hydrogen gas discharge during normal operation.
Flooded Battery
A lead acid battery with access caps for maintaining the electrolyte - replacing water
lost during recharge operations. Hydrogen gas discharged during normal recharge
OPERATION | This Package and SP LINK
Doc #OI0003 Part #004122 Rev14 2013
|
7
