6. ASSEMBLY, INSTALLATION AND COMMISSIONING
6.3.5

Hydraulic connection of the sensor

492639243-2
Adhere to the following sequence to connect the ContaminationSensor to the hydraulic
system:
1. Connect the return line to the outlet of the ContaminationSensor. Recommended
diameter of the pipe ≥ 4 mm.
2. Then connect the other end of the return line to the system tank, for example.
3. Check the pressure at the measurement location. Note the maximum operating
pressure.
4. Connect the instrument leads to the inlet of the ContaminationSensor. We
recommend an inner line diameter of ≤ 4 mm in order to prevent particle deposits
(sedimentation).
5. If particles ≥ 400 µm are anticipated in the hydraulic system, install a strainer in
front of the ContaminationSensor. (for example, CM-S). This prevents the
measurement cell from clogging.
6. Connect the other end of the measurement line to the measurement point on the
hydraulic system.
7. Oil begins to flow as soon as the ContaminationSensor is connected with the
pressure line.
8. The hydraulic connection is complete.
6.4

Electrical connection

492749323-2
To ensure that the product performs optimally, an important component is the electrical
connection / the correct integration, for example, in the power supply and / or interfaces.
The electrical connection for the sensor is created using the 8-pin plug. The contact
assignment can be found here.
