5. Assembly Instructions
Following is important information and instructions for assembling and maintaining
your new electric bicycle.
Step 1: Unpacking Your Bike
• Open the box. You may need a box knife to cut tape. Watch-out for staples
and sharp edges as you lift the bike out of the box. A helper can make this
easier. Do not lay the box out flat and cut the bike out as you may damage the
bike. HOT TIP: Use needle nose pliers to remove the staples before pulling the
bike out of the box. This will insure they do not scratch you or the bike.
• Cut all packing zip ties. Detach all parts that are tied to the frame. Be careful
not to cut/scratch the bike, particularly the tires and cables when removing
the ties.
• Do not attempt to rotate the handlebar/fork until all zip ties and packing have
been removed, otherwise you may damage the bicycle. Carefully examine
the carton for loose parts and make certain that no parts are remaining in
the box. Keep the box and packing material for a short time in case the bike
needs to be returned.
• Examine your new bike for any visible damage which may have occurred
during shipping.
01 - Tires
Check for cuts and wear,
maintain pressure indicated
on tires wall for maximum
efficiency.
02.03 - Wheel
Check that axles are sealed and
secured properly. Rim should be
kept free from wax, oil, grease,
and glue. Check for loose or
missing spokes, (see warning
below).
04 - Wheel Hub
Grease bearings annually. Adjust
cones to avoid free play side to
side without binding.
7
09 - Stem and Handlebar
Ensure stem nuts and bolts
are tight. Check handlebar
bolt is tight. Check brake lever
securely mounted to bars and
brakes stop smoothly and
efficiency.
10.11.21.26.29 -
The Electrical Parts
You can refer to the manual for
electrical parts.
12 - Grip
Check that they are clean and
tight.
25 - Chain
Lubricate as needed (this will
depend on usage and riding
conditions).
27 - Cranks
Check for loose bolts on both
arms and rings.
28 - Pedals
Check for looseness.
NOTE: left side is left-hands
thread.
