List of E-Bike Component Names
19
20
21
22
23
1. Tires & Tubes
2. Rims
3.
Spokes
4. Front Hub with QR
5. Front Mechanical Disk Brake
6. Front Suspension Fork
7. Front Mudhuard (Fender)
8. Shift Lever & Brake Lever
9.
Handlebar & Stem
10. Display
11. Throttle
12. Grip
13. Front Light
14. Frame
15. Saddle
1
15
18
16
26
25
27
24
Fig. 1 Electric Bicycle
11
12
13
14
17
29
28
16. Seatpost
17. Seat Post Clamp
18. Rear Light
19. Rear Mudguard (Fender)
20. Rear Mechanical Disk Brake
21. Rear Motor Hub
22. Kickstand
23. Freewheel
24. Rear Derailleur
25. Chain
26. Controller
27. Chainwheel/Crankset
28. Pedal
29. Battery
10
09
08
07
06
05
04
03
02
01
