Retrospec Chatham REV 2 Assembly Instructions Manual

Electric beach cruiser bike - 350w
Hide thumbs

Advertisement

Quick Links

Download this manual
Electric Beach Cruiser Bike - 350W
Assembly Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Chatham REV 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Retrospec Chatham REV 2

Summary of Contents for Retrospec Chatham REV 2

  • Page 1 Electric Beach Cruiser Bike - 350W Assembly Instructions...
  • Page 2 We strongly recommend taking your bike to a local bike shop after assembling so a professional, reputable bike mechanic can check your work and perform all necessary safety checks prior to the first ride. To find a Retrospec dealer near you, please visit https:/ /retrospec.com/pages/store-locator.

  • Page 3: Table Of Contents

    If the conditions in this manual are breached, the warranty will be Should any original component prove defective in terms of workmanship within its void automatically. warranty period, we will replace it. Warranty period for Retrospec electric bikes is as follows: 2. Saddle and Handlebar Set-Up The saddle can be easily moved either up or down.

  • Page 4: Routine Maintenance Checks And Lubrication

    After you have made any adjustment to your electric bicycle, check that all nuts WARNING! Handlebar stem minimum insertion mark on traditional quill stem and bolts are securely tightened and cables are free from kinks and fixed securely must NOT be visible above the top of the headset. If the stem is extended beyond to the electric bicycle frame.

  • Page 5: Assembly Instructions

    5. Assembly Instructions Step 2: Front Wheel & Front Fender Installation Following is important information and instructions for assembling and maintaining your new electric bicycle. 2.1 Installing the Front Wheel Step 1: Unpacking Your Bike Remove the plastic dropout protector from the metal shipping axle (Fig. 6). Unscrew and remove the metal shipping axle from the fork dropouts.
  • Page 6 Step 3: Seat Assembly (Refer to Fig. 8) Step 4: Handlebar & Handlebar Stem Assembly (Refer to Figs. 10 & 11) 3.1 - Assembling the Saddle onto the Seatpost: The handlebar has been pre-assembled together with brake levers, shifter levers and grips.
  • Page 7 Step 5: Installing Pedals (Refer to Fig. 12) Brake Lever/Cable Adjustment: To adjust the travel of the brake lever, loosen the Locking Collar A1 (away from The pedals are marked with either a “R” (Right) or “L” (Left) on the threaded end lever body), turn/unscrew the Adjusting Barrel A2 (what the cable enters) left/ of the pedal axle.
  • Page 8 B. Checking Brake Pad Wear, Pad Replacement Step 7: Derailleur Gears Maintenance and Adjustment Pads that are 1mm thick (or less) need immediate replacement (Fig. 15). The gears/derailleur(s) on your bicycle should be correctly adjusted from the To install new pads, remove the brake caliper from the fork or frame by factory.
  • Page 9 • Rear Derailleur Adjustment: Operate the shift lever to shift the chain from top gear to 2nd gear. There are two limit adjustment screws on the rear derailleur - High/”H” and • If the chain will not move to the 2nd gear, turn the cable adjusting barrel on Low “L”.
  • Page 10 3. Battery Installation & Usage • We strongly advise wearing an approved helmet which meets local safety Retrospec Chatham Rev 2 36V/350W E-bikes have the battery positioned standards. on the rear of the seat tube. The battery housing (that which the battery slides •...

  • Page 11: Riding Conditions

    4. LED and Functions Fig. 1 4.3 Selecting Pedal Power Assistance Level on Handlebar Display Panel: There are four buttons on the T320 display. Including power switch, up button, When the power is on, you can shift to 5 pedal power assistance levels from low to down button and Walk Assist button.
  • Page 12 FINALLY, close the charging socket cover on the battery - make sure it is securely closed. 7. Using and Maintaining the Electric Hub Motor. Retrospec intelligent e-bikes are programmed to start with the electric assistance (“Start-Aid”) after a rotation of the pedals (crankset). •...
  • Page 13 NOTE: If you think water may have got into the control box, switch-off the power Error Code Definition Table immediately and pedal without electric assistance. You can pedal with electric Error Code Description assistance as soon as the controller has dried out. As with the battery, hub, display and other electrical parts - Never strongly shake, PAS level 1 light flashing Current abnormal...
  • Page 14 7. Grey (throttle signal SP) 7. Blue (motor H1) 8. White (brake signal BKL) Model 8. Black (ground) 9. White (wheel speed signal) Chatham Rev 2 36V/350W IV. Display wire is connected V. Brake lever wire is connect- Vl. Throttle with the display ed with the brake lever 1.
  • Page 15 Making nature second nature.
