Installation instructions
7. Select the spindle.
4.3
Install the mechatronic unit
Open the housing
1. Remove the guide ring (4), metal
ring (3) and housing (2), whilst
pushing against the spindle.
2. Remove the batteries.
3. Remove the contact protection
film.
Kaba c-lever compact
k2evo703en-2014-01
Installation
8 mm
7 mm
8,5 mm
9 mm
x
1
2
3
4
13
