  • Page 1 LD450 Pushbutton Lock Installation Instructions...

  • Page 2: Table Of Contents

    J. Trouble Shooting ............8 Warnings and Cautions Important: Carefully inspect windows, doorframe, door, lights, etc. to ensure that the recommended procedures will not cause damage. Kaba Access Control’s warranty does not cover damages caused by installation. Caution: Wear safety glasses when preparing door.

  • Page 3: Checklist

    CHECKLIST Use this checklist to make sure that everything has been included. J A – Outside unit B – Inside unit C – Gaskets (2) D – Universal trim plate (2) E – Tailpieces / spindles (3 lengths) F – Latch G –...

  • Page 4: Determining The Hand Of Your Door

    A. DETERMINING THE HAND OF YOUR DOOR Many of the installation instructions refer to RH - Right Hand the handing of your door. The hand of the door is determined with the door in the closed position, from the exterior or pushbutton side of the door. A) Right Hand Door.

  • Page 5: Installing The Latch Support Post

    D. INSTALLING THE LATCH SUPPORT POST Install the latch support post into the back of the lock as shown. For right-hand doors, use hole A. Fit the latch support post in hole A For left-hand doors, use hole B. for a right hand hung door. Use B for a left hand hung door.

  • Page 6: Installing The Strike Plate

    F-7 Finger-tighten the (2) mounting screws, assuring the lock is vertical and sitting flush against the door. F-8 Before final tightening, make sure the code works and all features on the unit work as intended. Note: Do not close the door until the lock has been tested and you are confident it works properly.
  • Page 7 FOR POSITION ” (70 mm) Backset ONLY. From outside, fo ” (60 mm) Backset ONLY. From outside, fo...
  • Page 8 ONLY old along the right edge of the door old along the right edge of the door ” (130 mm)

  • Page 9: Changing The Code

    I. CHANGING THE CODE Remove the lock from the door. Remove the 4 retaining (red) screws from the back of the outside unit assembly. RED CODED Square Take extra care to keep the outside unit TUMBLER cut out assembly on a flat surface when you are removing the cover plate because there are many small components inside.

  • Page 10: Trouble Shooting

    J. Trouble Shooting Installation Issues: The latch cannot be withdrawn when entering the code   The lock has been fitted to the wrong hand hung door All locks were set to fit right-hand hung doors. The lock needs to be removed from the door and reversed.
  • Page 13 Kaba Access Control analysis to be defective during this period. Our only liabili- ty, whether in tort or in contract, under this warranty is to repair or replace products that are returned to Kaba Access Control within the one (1) year war- ranty period.
