Summary of Contents for Kaba C-lever Compact
- Page 1 Kaba c-lever compact Installation instructions Doc no.: k2evo703en-2011-05...
- Page 2 Fax: +41 (0) 44 931 63 85 www.kaba.at www.kaba.de www. kaba.ch Kaba® is a registered trademark of Kaba AG. This documentation may not be reproduced in any way or otherwise used without the written consent of Kaba GmbH. Copyright by Kaba GmbH...
-
Page 3: Table Of Contents
........ - Page 4 Possible faults ..........21 k2evo703en-2011-05 Kaba c-lever compact...
-
Page 5: Please Read First
Please read first Validity These instructions describe installation, maintenance and troubleshooting tips for the Kaba c-lever compact and are valid for the 2724 MID, 2725 MID, 2724 LEA and 2725 LEA variants. Target group These instructions are addressed to specialist staff for the assembly, installation, set-up, service and maintenance of this product. -
Page 6: Hazards To Personnel
Definition of terms In order to make it easier to read these instructions, the Kaba c-lever compact is shortened to actuator, the 1460 programming device is shortened to programmer and the Kaba evolo Manager software is shortened to KEM. -
Page 7: Safety And The Environment
Safety and the environment Safety and the environment Proper use The Kaba c-lever compact may only be used and operated for its intended purpose, i.e. opening and closing doors. Other uses are not permitted. Safety guidelines for this product 2.2.1 ESD protective measures ATTENTION Danger of damage to electronic components from electrostatic discharge. -
Page 8: Disposal Of Packaging
Disposal of Waste Electrical and Electronic Equipment [Verordnung über Entsorgung von Elektro- und Elektronik-Altgeräten] (VREG/WEEE) at a local collection point for waste electronic equipment. Conformity This actuator fulfils the requirements of the R&TTE Directive 1999/5/EC and the EMC Directive 89/336//EEC. Kaba c-lever compact k2evo703en-2011-05... -
Page 9: Product Description
The door thickness must be between 39 mm and 94 mm. 3.3.2 Lock requirements The Kaba c-lever compact can be used with most commercially available door locks. Only use locks from established manufacturers, as this is the only way to ensure that rosette drillings conform to the standards. -
Page 10: Technical Specifications
(chlorine, ammonia) Rooms Not to be used in environments where there is a risk of explosion Standards Fire protection According to EN1634-1 EN179 According to test certificate Key: The temperature range depends on the battery manufacturer's specifications Kaba c-lever compact k2evo703en-2011-05... -
Page 11: C-Lever Compact Assembly
Installation instructions Product description c-lever compact assembly Exploded diagram Position Description Mechatronic unit Housing Metal ring Plastic guide ring External handle Direction pin Batteries, type AAA Lithium (2 pieces) Spindle Fastening screw Internal rosette "round" (optional) Fixing screw for internal rosette (2 pieces) -
Page 12: Installation
4. If there are no rosette drill holes, drill the fixing holes with a Ø7.2 mm drill from both sides of the door (e.g. according to DIN 18255 standard). 5. After drilling, clean the mortise and refit the door lock. Kaba c-lever compact k2evo703en-2011-05... -
Page 13: Assembling The Mechatronic Unit
(1) anti-clockwise for right-hand doors, and clockwise for left-hand doors, as far as the limit stop when inserting the direction pin (6)! Inserting batteries 2. Insert batteries (7) into the mechatronic unit (1) as shown. Ensure correct battery polarity! Kaba c-lever compact k2evo703en-2011-05... -
Page 14: Installing The Actuator In The Door
(8) through the lock hub in the door. Fit the internal rosette 2. Fit the optional internal rosette (10) with plastic attachment downwards on the inside of the door and secure with fixing screws (11). Kaba c-lever compact k2evo703en-2011-05... - Page 15 Installation instructions Installation 3. Fit the cover (12) over the internal rosette (10). 4. Push the handle (13) onto the spindle (8) until there is an audible click and fix with a fixing screw (14). Kaba c-lever compact k2evo703en-2011-05...
-
Page 16: Operation
2 beeps with B structure with a further 15 out upon after a further 15 seconds programming master B secs, successful confirms the reset of all initialisation master media. Kaba c-lever compact k2evo703en-2011-05... -
Page 17: Maintenance And Troubleshooting
Maintenance and troubleshooting Maintenance The Kaba c-lever compact requires no mechanical or electronic maintenance! ATTENTION Opening the coupling unit absolves Kaba of any liability under the guarantee! 6.1.1 Replacing the battery Risk of explosion Lithium batteries can explode or burst explosively. -
Page 18: Setting The Clock
Programmer, provided that the function has not been previously deactivated in the KEM software. See Programmer user manual. The events and data that are registered in the Traceback are listed in the kaba evolo system description. Kaba c-lever compact k2evo703en-2011-05... -
Page 19: Emergency Opening For Discharged Batteries
- Unlocking from the inside 1. With a panic lock, the Kaba c-lever compact can always be unlocked by operating the handle. The relevant locking function is otherwise ensured by moving the inner handle. -
Page 20: Ini Reset
The facing of the actuator may be damaged by the use of inappropriate cleaning agents or methods. Use a soft, damp cloth to clean the facing. Only disinfection agents that are specifically designed for delicate metal facings and plastics should be used. Kaba c-lever compact k2evo703en-2011-05... -
Page 21: Troubleshooting
Set clock close at programmed Incorrect programming Replace coupling unit time Door cannot be opened 8 x short 8 x red System test not Check and/or change with programmed completed correctly cable connections and medium coupling unit Kaba c-lever compact k2evo703en-2011-05... - Page 22 Installation instructions Notes Kaba c-lever compact k2evo703de-2011-05...
- Page 23 Notes Installation instructions k2evo703de-2011-05 Kaba c-lever compact...
- Page 24 Installation instructions Notes Kaba c-lever compact k2evo703de-2011-05...
