Advantech AIMB-308 Startup Manual

AIMB-308 Proprietary Motherboard
with 12th Gen Intel
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• AIMB-308
• Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website at:
https://www.advantech.com/support
This manual is for the AIMB-308 series Rev.A1.
Part No. 2041030800
Printed in China
Core i CPU Socket (LGA 1700)
® TM
Specifications
Standard Functions
• CPU: LGA 1700 12th Gen Intel
eron/Pentium
• BIOS: AMI 256Mbit SPI BIOS
• Chipset: Intel
• System Memory: Dual DDR4 3200 MHz, 32GB per 288-
pin slot without ECC function. Max. capacity to be 64GB
• SATA interface: Three on-board Serial ATA 3.0 connec-
tors support data transmission rates up to 600 MB/s.
All three SATA 3.0 support Advanced Host Controller
Interface (AHCI) technology
• PCIe slot: One PCIe x16 and one PCIe x4 expansion slot
• USB 3.2/2.0: Dual USB 3.2 Gen1 and dual 2.0 on both
rear and front side
Graphic Interface
• Chipset: CPU integrated graphics controller
• Display port: Resolution up to 4096x2304 @60Hz
refresh rate
• HDMI: Resolution up to 4096x2160 @30Hz refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: (LAN1) Intel
Mechanical and Environmental Specs.
• Dimensions (L x W): 290.2 x 207.5 mm
• Power supply Voltage: +12V, +5Vsb
• Operating temperature: 0 ~ 40 °C (32 ~ 105 °F)
• Weight of board: 0.526 kg (1.16 lbs)
1st Edition
July 2022
Core™ i9/i7/i5/i3/Cel-
®
H610E PCH
®
I219-V; (LAN2) Intel
®
AIMB-308 Startup Manual 1
I226-V
®
