Table Of Contents; Support Information - Chore-Time 27150LM Installation Manual

The Chore-Time Fans are designed to be used as circulating or exhaust fans. Using this equipment for any other
purpose or in a way not within the operating recommendations specified in this manual will void the warranty and
may cause personal injury and/or death.
This manual is designed to provide comprehensive planning, installation, wiring,
operation, and parts listing information. The Table of Contents provides a conve-
nient overview of the information in this manual. The Table of Contents also spec-
ifies which pages contain information for the sales personnel, installer, and
consumer (end user).
IMPORTANT: CE stands for certified Europe. It is a standard which equipment
must meet or exceed in order to be sold in Europe. CE provides a benchmark for
safety and manufacturing issues. CE is required only on equipment sold in Europe.
Chore-Time Equipment recognizes CE Mark and pursues compliance in all appli-
cable products. Fill in the CE-Mark serial number in the blank space provided for
future reference.
Please fill in the following information about your fans. Keep this manual in a clean,
dry place for future reference.
Distributor's Name
Distributor's Address
Distributor's Phone
Installer's Name
Installer's Address
Installer's Phone
System Specifications
Topic
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Support Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Fan Assembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Fan Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 7
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
36" Belt Drive Panel Fan Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
* L e g e n d : C = C u s t o m e r ( e n d u s e r ) , D = D i s t r i b u t o r ( s a l e s ) , I = I n s t a l l e r o f e q u i p m e n t
36" Belt Drive Panel Fan Installation Manual
Su ppo r t I nf or ma ti o n

Table of Contents

Tools Required for Installation
Hammer & Nails
Flat Head Screwdriver
Open End Wrenches (standard)
Adequate Size and Quantity of Wire
• Page 3
Date of Purchase
Date of Installation
(CE-mark serial number)
Page User*
C, D
C, D
C, I
I
I
C
C, I
