Fixed Rails

This section describes how to mount the appliance in a rack with fixed rails.
Important - Two people are required to install the appliance in a rack
to prevent any possible damage.

Rack Mounting Hardware and Tools

You must install rack mounting hardware on the appliance before you mount it
in a rack.
Hardware
Description
Ear mount bracket
Ear mount screws
Appliance rail
Rail plates
Appliance rail
screws
Qty. Use
2 Attaches to the appliance front panel. Both ear
mount brackets are identical.
6 Secures the ear mount brackets to the appliance
front panel. These screw heads are smaller (5
mm).
2 Attaches to the appliance. Both rails are
identical.
2 Attaches to the appliance rails. Both plates are
identical.
14 Secures the rail plates to the appliance rails and
the rails to the appliance. These screw heads are
larger (8 mm).
3
