Check Point 4000 and TE250
Appliances Installing and Removing
Memory
70720 5
Protecte d
2017
Important - We recommend that only experienced personnel install or
remove hardware components. Installing or removing components
incorrectly can permanently damage the appliance.
Preparing the Appliance
Before you start to install or remove memory DIMMs, make sure that:
•
You can connect to the WebUI or CLI to shut down the appliance.
•
The appliance is in a clean environment and on a level surface.
•
You can physically access and open the cover of the appliance.
•
You have the Check Point memory DIMM upgrade kit.
Classification [Protected]
© 2017 Check Point Software Technologies Ltd. All rights reserved.
For a list of our trademarks, please refer to: www.checkpoint.com/copyright.html.
For a list of our Third Party Copyright notices, please refer to:
www.checkpoint.com/3rd_party_copyright.html
P/N:707205

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Check Point 4000

Summary of Contents for Check Point 4000

  • Page 1 You have the Check Point memory DIMM upgrade kit. Classification [Protected] P/N:707205 © 2017 Check Point Software Technologies Ltd. All rights reserved. For a list of our trademarks, please refer to: www.checkpoint.com/copyright.html. For a list of our Third Party Copyright notices, please refer to:...
  • Page 2 We recommend that you use the grounding wrist strap that is included in the upgrade kit. The grounding plug on the rear of the appliance provides a chassis grounding point. Upgrade Kit Contents • Installation guide - Check Point 4000 and TE250 Appliances Installing and Removing Memory • Memory DIMMs •...
  • Page 3 Check Point 4200 Appliance Item Description Appliance cover Two appliance cover screws Check Point 4400 and 4600 Appliance Item Description Appliance cover Two appliance cover screws...
  • Page 4 Check Point 4800 and TE250 Appliance Item Description Appliance cover Four appliance cover screws...
  • Page 5 4200 Appliance DIMM Configuration The default memory configuration for the 4200 appliance is two 2 GB DIMMs, one in the lower slot and one in the upper slot. There is a total RAM of 4 GB. To upgrade a 4200 appliance to an 8 GB configuration: 1.
  • Page 6 To remove a memory DIMM from the appliance: 1. Find the DIMM memory socket on the system board. The basic memory configuration of the appliance ships with two 2 GB DIMMs installed. 2. Using your index fingers, press on the white retaining clips outward. 3.
  • Page 7 To insert memory DIMMs in the appliance: 1. Find the DIMM memory socket on the system board. 2. Align the DIMM diagonally to the lower memory socket. Note - The top of the DIMM is smooth. The bottom edge has two different-length sets of contacts, which connect to the slots on the socket.

  • Page 8: Default Configuration

    4400, 4600, 4800 and TE250 DIMM Configuration The 4400, 4600, and 4800 appliances have a default memory configuration of one 4 GB, with one DIMM in memory socket number 1. The TE250 appliance has a default memory configuration of 8 GB, with two 4 GB DIMMs in memory sockets 1 and 2.
  • Page 9 Procedure Slots upgrade DIMMs 8 GB 2 x 4 GB Install one additional 4 GB In blue memory socket DIMM number 2 Upgraded Configuration for 4400, 4600, and 4800 Appliances / Default Configuration for TE250 Appliance Top View (front panel of the 4400, 4600, 4800, and TE250 appliance is at the bottom of the diagram)
  • Page 10 Installing 4400, 4600, 4800, and TE250 Memory DIMMs To install memory DIMMs in the appliance: 1. Find the DIMM memory slots on the system board. The basic memory configuration of the 4400, 4600, and 4800 appliances ship with one DIMM installed. 2.
  • Page 11 4. Press the new DIMM into the socket until it clicks into position. The retaining clips move into the lock position as you press the DIMM into position. Important - Make sure that there are no leftover parts inside the appliance. 5.
  • Page 12 Attaching the New Warranty Sticker After you install one or more new DIMMs, attach the new warranty sticker on the appliance. Important - Failing to attach the new warranty sticker correctly will void the warranty of the appliance. To attach the new warranty sticker: 1.
