Acquisition mode

The LEDs provide the following information during acquisition (partnership) .
System status
Part
setter
Interface in
"Acquisition
waiting" state
Interface
identifies part
setter
Interface
identifies tool
setter
Part setter
and tool setter
identified
The part setter
is acquired
(tool setter
acquisition
pending)
Tool setter
acquired
(part setter
acquisition
pending)
Part setter
acquired
Tool setter
acquired
Part setter
and tool setter
acquired
Graphic display
Low
credit/ Probe
Start
low status
battery
Tool
Error Signal
setter
www.renishaw.com/primo
Details
The part setter/tool
setter LEDs flash yellow/
off (at least once) for up
to 11 seconds or until a
part setter/tool setter is
discovered .
The part setter LED
flashes green for up
to 3 minutes or until
an "acquisition ready"
message is received from
the part setter .
The tool setter LED
flashes green for up
to 3 minutes or until
an "acquisition ready"
message is received from
the tool setter .
Both LEDs flash green for
up to 3 minutes or until
an "acquisition ready"
message is received from
the equipment .
The part setter LED is on
and the tool setter LED
flashes for 3 minutes
or until the tool setter is
acquired .
The tool setter LED is on
and the part setter LED
flashes for 3 minutes or
until the part setter is
acquired .
The part setter LED stays
on for 5 seconds.
The tool setter LED stays
on for 5 seconds.
The part setter and tool
setter LEDs stay on for 5
seconds .
