Connection to the EU-MW-1 module:
Heating
device
V. FIRST START-UP
In order for the controller to operate correctly, the following steps must be followed for the first start-up:

1. Setting up the Internet connection

2. External sensor configuration (optional)
3. Configuration of the temperature sensor or room controller
4. Configuration of STT-868/STT-869/EU-G-X wireless thermostatic actuators
5. Window opening sensor setup.
1. SETTING UP THE INTERNET CONNECTION
The EU-T-5z WiFi has a built-in Internet module, which allows you to control the installation via the Internet. First of all,
you need to connect to the Internet – using the <WiFi network selection> option in the controller menu to connect to
the selected WiFi network. The parameters of the Internet module such as: IP address, IP mask, Gateway address – can
be set manually or the DHCP option can be enabled (option enabled by default).
You must then register your account at https://emodul.eu/. After enabling the <Registration> option in the driver menu,
a code will be generated, which should be entered on the https://emodul.eu/ website in the <Settings> (Register
module) tab.
2.

EU-C-8ZR EXTERNAL SENSOR CONFIGURATION

The external sensor must be registered. To do this, select the <Registration> icon in the EU-T-5z WiFi controller (Main
Menu > External Sensor > Registration), and then press the communication button (one short press) on the external
sensor. The registration will automatically activate the external sensor. After registering, you may disconnect it at any
moment by checking the <OFF> option.
LED
8
Channel change
button
