5.

WINDOW OPENING SENSOR SETUP

To register the window opening sensor, select the zone in the EU-T-5z WiFi menu, then the Window
Sensors/Registration option, then briefly press the communication button on the window sensor.
After releasing the button, observe the indicator LED:
•
- double blinking of the indicator LED – correct communication
•
- indicator LED is on with a continuous light – no communication with the main controller.
VI. MAIN SCREEN DESCRIPTION
1. LED
2. Controller display
3. EXIT button. From the home screen position, pressing this button will bring up a submenu to select the home
screen view (Wi-Fi screen or Zone screen). After entering the controller menu, it is used to cancel the settings, or
exit the submenu.
4. PLUS button - After entering the controller menu, it is used to browse functions, or increase the setting values.
5. MINUS button - When entering the controller menu, it is used to browse functions, or decrease the setting values.
6. MENU button. Entering the controller menu, confirming the settings.
NOTE
The controller has a motion detection function. When motion is detected at a distance of approximately 2 cm
from the touch buttons, the controller display will illuminate.
1
2
3
4 5
10
6
