2.9.

WINDOW SENSORS

•
Registration – To register a sensor, select the "Registration" option, and then briefly press the communication
button on the window sensor. After releasing the button, observe the indicator LED:
- double blinking of the indicator light – correct communication
- indicator light is on with a continuous light – no communication with the main controller.
•
Sensor removal – with this function, the user has the option to delete the sensors in the zone.
•
Information – this option is only available when the sensor is registered. With this option, the user can view
information about sensor range and battery status.
•
Settings – the function allows you to set the delay time. After the preset delay time, the main controller sends
information to the actuators about the need to close them. Time range 0 - 30 min.
Example: The delay time is set to 10 min. Once the window is opened, the sensor sends information to the main
controller about opening of the window. The sensor confirms the current state of the window from time to time. If after
10 minutes the window remains open, the main controller will close the actuator and switch on the overheating of the
zone.
NOTE
If the delay time is set to 0, then the signal to the actuator to close will be transmitted immediately.
3.

OPERATING MODE

3.1. NORMAL MODE

The pre-set temperature depends on the set mode of operation in the zone.

3.2. HOLIDAY MODE

The pre-set temperature depends on the setting in the "Temperature settings" function (Menu > Zones > Temperature
settings > Holiday mode).

3.3. ECONOMICAL MODE

The pre-set temperature depends on the setting in the "Temperature settings" function (Menu > Zones > Temperature
settings > Economical mode).

3.4. COMFORT MODE

The pre-set temperature depends on the setting in the "Temperature settings" function (Menu > Zones > Temperature
settings > Comfort mode).
4.

EXTERNAL SENSOR

You can connect an external temperature sensor to the controller, which allows you to view the current temperature on
the main screen and in the https://emodul.eu app
After installing the external sensor, register it in the EU-T-5z WiFi controller - The registration process is described in
detail in the First start-up section.
After registering the sensor, the user can view current battery status and signal strength, and also has the option to
calibrate the sensor. The external sensor is not involved in the control process.
15
