EU-295v3
230V
NOTE
The marking on the back of the controller refers to the built-in transmitter. It does not refer to the type of
actuator connected.
NOTE
The regulator is powered with batteries, which should be periodically checked and replaced at least once every
heating season. In order for the control circuit to operate properly, it is necessary to provide the regulator with
230 V AC power supply, as illustrated in the diagram.
IV. FIRST START-UP
Follow these step while starting the controller for the first time to ensure proper operation:
1. Remove the front cover and insert the batteries.
2. Connect the regulator to the actuator as illustrated in the diagram.
6
