Tech Controllers EU-T-5z WiFi User Manual page 22

Clicking in the Schedule icon area, we go to the weekly schedule selection screen:
Weekly schedule selection screen
There are two types of weekly schedules in the EU-T-5z WiFi controller:
1. Local schedule
This is a weekly schedule default assigned to the zone. When a room sensor is detected by the EU-T-5z WiFi controller,
it is automatically assigned as valid in the zone. It can be edited at will.
2. Global Schedule (Schedule 1...5)
This is a weekly schedule assigned to the zone. It is possible to create a several different schedules for the zone, from
which we can choose only one.
After selecting the schedule and clicking OK, we go to the Edit weekly schedule settings screen:
Weekly schedule edit screen
22
